lO6OCD/lO'lOCD (k
)COVER( 98.4.240129EM y I W 2
MULTIPLE CD PLAYER
1 O6OCD/107OCD
DP-R6090/R7090
D-R350
SERVICE MANUAL
KENWOOD
© 1997-7/851-5326-00 (K/K) 3654
Escutcheon Front glass
(307-2294-22)
(810-2364-03)
Knob assy
(K29-6681-24)
KENWOOD
am usuum
Knob (BUTTON) Panel
(K27-2178-04) (A60-)
Power cord bushing Slide switch Phono jack
(J42-0083-05)
(831-2132-05) (E63-O199-05)
Phone jack
(E11-0127-05)
Metallic cabinet
(AO1-3289-01)
uranium , svsIEM Damn-7L
Lxxa
,_ EVEN.
21:1:an nPucAL
'QIE
E @
TEXT
1mm nume
I
AC power cord Phono jack
(E30-) (EGG-100905)
Miniature phone jack
(E11-0293-05)
Oscillating module
(W02-1114-05)
In compliance with Federal Regulations, following are reproductions of
labels on, or inside the product relating to laser product safety.
KENWOOD-Corp. certifies this equipment conforms to DHHS Regulations
No. 21 CFR 1040. 10, Chapter 1, Subchapter J1
DANGER : Laser radiation when open and interlock defeated.
AVOID DIRECT EXPOSURE TO BEAM.
Illust is DP-R6090.
* Refer to parts list on page 21.
