TECHNICAL SPECIFICATIONS

Product 107/2

Desmpn'm 3-way 4 driver iloorsianding loudspeaker

Drive Units: HF Unit 1 x T33 25 mm (1") Meral Dome high frequency unis
MF Unit 1 x B110 110 mm (5") Polypropylene-coned midrange unit
LF Umrr 2 X 13250 250 mm (10") Pulprconed bass unils

Frequency Response ' 20 112.20 kHz : 2.5 dB (76 dB @ 18 Hz, Q=U.S)

Dimctt'orml Chamctemlm:

\Vflhin 2 dB of response on reference axis
up to 10 kHz for 1 10° verueiilly
up in 10 kHz for 1 30° horizontally

Height and Origin of 1020 mm (40") above base of eahiner
Refeience Axis (not including leer)

Angle a/Refmme Huntontal

Maximum Output =,~ . 112 dB

Chorartenrttt Smnvity Level .~ 90 dB . 7
memver Frequeneies. 3 kHz, 150 Hz

Amplifier Requitzmmis .-

Suitable for use with amplifiers capablc of providing
between $0 and 300 W into a 4 ohm resisLiVe load

Nominal Impedance:

4 ohm resistive from 20 Hz r 20 kHz

Enclosure Type:

Twin Coupled Caviry

Internal Volume: LF Emlaxme: 72 lines
MF Embxmt: 8.5 lines
Net Weight: 45 kg (99 1b)

Dimensiom: {h at w x d) mm

1165 x 330 X 448

in.

45.9 x13 x17.6

Notes:

1. Measured at 2 m on refuence axis.

2. Maximum spl, measured ar 2 m, on programme peaks under rvpical listening conditions.
3. Measured in 1 m on reference axis for pink noise input «2.23 v rms, band limited 50 Hz - 20

kHz (anechoie conditions)

4. Amplifier requirement figures are intended only as a guide. As a general rule buy Lhe higgesr
amplifier you can afield widiin the specified range and use ii with care. It is easier to damage
the loudspeaker by using a small amplifier driven iniu distortion by too much volume wish bass
and treble boost, than by using a larger amplifier which has power in reserve. If in doubt, ask

ynur dealer.

TECHNICAL SPECIFICATIONS

Product: KUBE 107/2

Descriplwm Active equaliser providing fixed and variable equalisaLion

User Cannals: LF Camouv Continuously variable shelf Carmel allowing boost of
attenuation over the range +4 to -6 dB. Shelf centre
frequency 160 Hz

HF Contour Continuously variable eonuol allowing boost or

attenuation over [he iange +2 5 io .35 dB. Cenu-e
frequency 4.5 kHz.

Tape Mwntur: Push button conuuls [ape input/output via rear socketsr

Bypass EQ: Push burron by-passes user-variable equalisacion only.

Rear Panel Cmmettiam:

All signal inputs and ouipuis via gold plated phone (RCA)
sockeis. Power in (low volmge AC) viii 5-pin DIN oenneeier

Input Impedance:

5 l kohms

Maximum Input Voltage:

> 1.9 V [ms above 20 Hz
> 8 V rms above 50 Hz

Mom'mm Output Wltagz: > 5 v rms
Output Impedance: 100 ohms
Output Noise tenet: < 6 uv A-weighted

Signal-wmee Ratio:

> 104 dEA ref 1 V rms

Dtllwm'vn: < 0.005% for 1 v rms inpur @ 1 kHz

Power Supply: 23 v AC @ 0.3 A from factory supplied power supply
adapier

Net Weight; 1.30 kg (2.87 lb)

Dimenohtis: (h x w x d} mm
m

65 x [52 x 234
2.6 x 6.5 x 9.2

Features and speciiicanons sublect [0 change win-ion: notice. KEF is a nudes-nail: ofKEF Audio (UK) Limited.
