JVC
SERVICE MANUAL
MICRO COM PON ENT SYSYTEM
UX-G D7
Area suffix
B ------------------------------ U.K.
E -- - Continental Europe
EN - Northern Europe
EV --- Eastern Europe
EE -------- Russian Federation
SP-UXGD7 CAUXGD7 SP-UXGD7
[HEB at, UK] DOLBY DVD
D I G I T A '- AUDIO/VIDEg fihomc
mm: mm.
@ R -D-$ -, Digital Direct Progressive Scan
Lead free solder used in the board (material : Sn-Ag-Cu, melting point: 219 Centigrade)
TABLE OF CONTENTS
1 PRECAUTIONS ....................................................................... 1-3
2 SPECIFIC SERVICE INSTRUCTIONS ....................................... . .. 1-5
3 DISASSEMBLY ........................................................ . . . 1-6
4 ADJUSTMENT ......................................................... .. 1-17
5 TROUBLESHOOTING ................................................................. 1-17
COPYRIGHT © 2005 Victor Company of Japan, Limited No_MB422
2005/8
