JVC
SERVICE MANUAL
MICRO COMPONENT SYSTEM
UX-G3, UX-G4
UX-G3 UX-G4
Area suffix Area suffix
-- Australia
Singapore
-- Singapore
» Hong Kong
_________________ Taiwan Taiwan
Brazil,Mexico,Peru - Brazil,Mexico,Peru
-------------- Argentina
@ JVI: @
[@ng
. 7
spiuxes CAVUXGS spiuxes DIGITAL Auulo
SPVUXG4 CAVUXG4 spiuxe4
Lead free solder used in the board (material : Sn-Ag-Cu, melting point: 219 Centigrade)
TABLE OF CONTENTS
1 PRECAUTION ......................................................................... 1-3
2 SPECIFIC SERVICE INSTRUCTIONS ...................................................... 1-4
3 DISASSEMBLY ....................................................................... 1-5
4 ADJUSTMENT ................................. 1-16
5 TROUBLESHOOTING ................................................................. 1-19
COPYRIGHT © 2005 Victor Company of Japan, Limited No_MB429
2005/7
