Jvc TT 81 Service Manual
This is the 29 pages manual for Jvc TT 81 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Jvc TT 81 Service Manual (Ocr-read)
Page 2
CONTENTS
1 .
2.
3.
9?
seems»
10.
11.
12.
13.
14.
15.
16.
TT-81
Page
Specifications ........................................................ 2
Features ............................................................ 3
New Technical Information
3-(1) Block Diagram ................................................. 4
3-(2) Crystal Oscillator and Frequency Deviders ............................... 5
3-(3) Neon Lamp Circuit .............................................. 5
3-(4) Frequency Generator, Output Amp. Waveform and Phase Comparison ............ 6
3455) Drive Circuit .................................................. 7
3-(6) Reverse Turn Detection ........................................... 7
3-(7) Start/Stop Circuit ............................................... 8
348) Cut-off of Hall Element Drive Circuit .................................. 8
3491 Quick Stop Circuit .............................................. 8
Dismounting ......................................................... 9
Adjustment Procedures
5-") Power Supply Voltage ............................................ 10
5-(2) Lock Adjustment ............................................... 10
5-(3) Quick Stop Adjustment ........................................... 1 1
5-(4) Wow and Flutter Adjustment ....................................... 11
5-(5) Speed Adjustment .............................................. 1 1
Connections Wiring ..................................................... 12
Lubrication .......................................................... 12
Waveforms .......................................................... 13
Troubleshootings
9-(1) Turntable does not rotate .......................................... 14
9-(2) Turntable rotates at high speed and fails to stop ........................... 15
9-(3) Speeds increase when rotated in the reverse direction ....................... 16
9-(4) Neon Lamp does not light ......................................... 16
9-(5l Neon Lamp remains lit ........................................... 16
9-(6) Turntable rotates at an incorrect rpm .................................. 17
9-0) Speed Select button does not function ................................. 18
9-(8l Quick Stop does not function ....................................... 18
Exploded View and Parts List .............................................. 19
TAS-1QC Servo Control and Power Supply P.C. Board Ass'y ......................... 21
Packing Material Parts List ................................................ 26
Accessories List ....................................................... 27
Parts List with Specified Number for Designated Areas ............................. 27
Schematic Diagram ..................................................... 28
Diagram of TAS-1SC Printed Circuit Board Ass'y ................................. 29
No. 2390 - 1 -
