JVC
SERVICE MANUAL
DVD DIGITAL CINEMA SYSTEM
TH-S77
Area suffix
Singapore
----~ Korea
--------- Taiwan
- Saudi Arabia
\ l UG --- Turkey,South Africa,Egypt
UN ----------------------------- Asean
(SP-PWS77)
.2.
(SP»THS77F)(SP-THS77C)(SP-THS77F) (SP-THS77S)
(XV-THS77)
D I G I T A l
[flcumpm é DU N
US muse DIGITAL
mmowmso" SUPER VDEO ¥CD s u R R 0 u N D
Digital Direct Progressive Scan
Lead free solder used in the board (material : Sn-Ag-Cu, melting point: 219 Centigrade)
TABLE OF CONTENTS
1 PRECAUTION ......................................................................... 1-4
2 SPECIFIC SERVICE INSTRUCTIONS. . ........................ 1-7
3 DISASSEMBLY ....................................................................... 1-8
4 ADJUSTMENT ....................................................................... 1-20
5 TROUBLESHOOTING ................................................................. 1-25
COPYRIGHT © 2005 Victor Company of Japan, Limited NO.MB421
2005/7
