Jvc THP 3 Service Manual
This is the 61 pages manual for Jvc THP 3 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Jvc THP 3 Service Manual (Ocr-read)
Page 1
JVB
SERVICE MANUAL
DVD DIGITAL CINEMA SYSTEM
TH-P5B, TH-P5E, TH-P5EN, TH-P5EV,
TH-P3B, TH-P3E, TH-P3EN, TH-P3EV,
TH-G1OB, TH-G1OE, TH-G10EN, TH-G1OEV
TH-P5 TH -P3ITH -G1 0 SP-WPS/
sp.wp5 SP-THG1OW
SP-THPSS
@-
SP-THP3C/SPTHGI 0C
SP-THPSF/ SP-THPSS/
SP-THGlOF SP-THG1DS
,, 77 willlllll ::-
gllllllllll
,, llllllllll
@llllllll $5..
MPEG-4 25 @DSE Dupe-PHI édfi
ASF PI-AVBACK uuuuu Digital Surround UUUUU
Radio Data System Digital Direct Progressive Stan
(Only for TH-P5/TH-G10)
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)
TABLE OF CONTENTS
1 PRECAUTION ......................................................................... 1-4
2 SPECIFIC SERVICE INSTRUCTIONS ...................................................... 1-7
3 DISASSEMBLY ....................................................................... 1-7
4 ADJUSTMENT ....................................................................... 1-20
5 TROUBLESHOOTING ................................................................. 1-23
COPYRIGHT © 2008 Victor Company of Japan, Limited N0.MB512
2008/7
