Page 1
1-2 (No.MB672)
SPECIFICATION
TH-G40General
Power supply Refer to main label.
Power consumption Refer to main label.
Net Weight 4 kg
External dimensions (W x H x D) 430 x 72 x 307 mm
Operating conditions Temperature: 5 °C to 35 °C Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm CD/DVD
Video system NTSC
Frequency response (audio) 140 Hz to 20 kHz *
Signal-to-noise ratio (audio) More than 75 dB (1 kHz 20 kHz LPF/A-Filter) *
Dynamic range (audio) More than 75 dB *
Harmonic distortion (audio) 0.5 % (1 kHz at 1W position) (20 kHz LPF) * Video
Video output 1.0 V (p-p) 75 Ω negative sync. RCA jack x 1
COMPONENT VIDEO OUT (Y) 1.0 V (p-p) 75 ohms negative sync RCA jack x 1 (PB)/(PR) 0.7 V (p-p) 75 ohms RCA jack x 1
HDMI OUT 480p/720p/1080i/1080p Tuner (FM)
Tuning Range 87.5 - 108.0 MHz
Intermediate Frequency 10.7 MHz
Signal-to Noise Ratio 60 dB (Mono) *
Frequency Response 140 - 10,000 Hz * Amplifier
Stereo mode 155 W + 155 W (4 Ω at 1 kHz, THD 10 %)
Surround mode
(* Depending on the sound mode settings
and the source there may be no sound output.) Front: 155 W + 155 W (THD 10 %)
center*: 155 W
Surround*: 155 W + 155 W (4
Ω at 1 kHz THD 10 %)
Subwoofer*: 225 W (3 Ω at 70 Hz THD 10 %)
Inputs AUDIO IN, OPTICAL IN, AUX IN
Outputs MONITOR OUT HDMI OUT COMPONENT VIDEO OUT Speakers
Front/Rear Speaker Type 1 Way 1 Speaker Impedance 4 Ω
Frequency Response 120 - 20000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power155 W
Max. Input Power 310 W
Net Dimensions (W x H x D) 117 x 210 x 111 mm
Net Weight 0.9 kg
Page 2
(No.MB672)1-3
Items with * are measured at Front Speaker Terminals in STEREO mode
Designs and specifications are subject to change without notice.
TH-G40UJ center speaker Type 1 Way 1 Speaker
Impedance 4 Ω
Frequency Response 120 -20000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power 155 W
Max. Input Power 310 W
Net Dimensions (W x H x D) 300 x 115 x 111 mm
Net Weight 1.1 kg
Passive Subwoofer Type 1 Way 1 Speaker Impedance 3 Ω
Frequency Response 40 - 1500 Hz
Sound Pressure Level 82 dB/W (1m)
Rated Input Power 225 W
Max. Input Power 450 W
Net Dimensions (W x H x D) 236 x 435 x 391 mm
Net Weight 5.7 kg
General
Power supply 110-240 V ~ 50/60 Hz
Power consumption 130 W
Net Weight 4 kg
External dimensions (W x H x D) 430 x 72 x 307 mm
Operating conditions Temperature: 5° C to 35°C,Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser,wavelength 650 nm
CD/DVD
Video system NTSC
Frequency response (audio) 140 Hz to 20 kHz*
Signal-to-noise ratio (audio) More than 75 dB (1 kHz,20 kHz LPF/A-Filter)*
Dynamic range (audio) More than 75 dB*
Harmonic distortion (audio) 0.5 % (1 kHz,at 1W position) (20 kHz LPF)* Video
Video output 1.0 V (p-p),75 Ω,negative sync.,RCA jack x 1
COMPONENT VIDEO OUT (Y) 1.0 V (p-p),75 ohms,negative sync,RCA jack x 1 (PB)/(PR) 0.7 V (p-p),75 ohms,RCA jack x 1
HDMI OUT 480p/720p/1080i/1080p
Tuner (FM)
Tuning Range 87.5 - 108.0 MHz
Intermediate Frequency 10.7 MHz
Signal-to Noise Ratio 60 dB (Mono)*
Frequency Response 140 - 10000 Hz*
Amplifier
