G-1 Warnings, Cautions and Others/Avisos, Precauciones y Varios 1. CLASS 1 LASER PRODUCT 2.DANGER: Visible and invisible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam. 3.CAUTION: Do not open the top cover. There are no user service- able parts inside the Unit; leave all servicing to qualified service personnel. Caution ÐÐ button! Disconnect the XV-THA10 and SP-PWA10 main plugs to shut the power off completely. The button on the XV-THA10 in any position do not disconnect the meins line. The power can be remote controlled. CLASS 1 LASER PRODUCT Caution: Proper Ventilation To avoide risk of electric shock and fire and to protect from damage. Locate the apparatus as follows: Front: No obstructions open spacing. Sides: No obstructions in 3 cm from the sides. Top: No obstructions in 5 cm from the top. Back: No obstructions in 15 cm from the back Bottom: No obstructions, place on the level surface. CAUTION To reduce the risk of electrical shocks, fire, etc.: 1. Do not remove screws, covers or cabinet. 2. Do not expose this appliance to rain or moisture. 1CLASSIFICATION MARK, PLACED ON REAR ENCLOSURE 1ETIQUETA DE CLASIFICACIîN, COLOCADA EN PARTE POSTERIOR2WARNING LABEL, PLACED INSIDE THE UNIT 2ETIQUETA DE AVISO, SITUADA EN EL INTERIOR DE LA UNIDAD IMPORTANT FOR LASER PRODUCTS / IMPORTANTE PARA PRODUCTOS LASER REPRODUCTION OF LABELS / REPRODUCCIîN DE ETIQUETAS CAUTION: Invisible laser radiation when open and interlock failed or defeated. AVOID DIRECT EXPOSURE TO BEAM. (e) ADVARSEL: Usynlig laser- stråling ved åbning, når sikkerhedsafbrydere er ude af funktion. Undgå udsæt- telse for stråling (d) VARNING: Osynlig laser- strålning när denna del är öppnad och spärren är urkopplad. Betrakta ej strålen. (s)VARO: Avattaessa ja suo- jalukitus ohitettaessa olet alttiina näkymättömälle lasersäteilylle. Älä katso säteeseen. (f) Spacing 15 cm or more Espacio de 15 cm o m‡s Front Frente Wall or obstructions Pared u obstrucciones Floor Piso XV-THA10 Spacing 15 cm or more Espacio de 15 cm o m‡s Front Frente Wall or obstructions Pared u obstrucciones Floor Piso SP-PWA10 XV-THA10 SP-PWA10 Precauci-n ÐÐ Bot-n ! La forma de desconectar completamente el suministro elŽctrico para el XV-THA10 y el SP-PWA10 es desenchuf‡ndolo de la red. El apagado mediante el bot-n mantiene ua conexi-n de tensi-nque permite el encendido del XV-THA10 utilizando el mando a distancia. PRECAUCIîN Para reducir el riesgo de descargas elŽctricas, fuego, etc.: 1. No quitar los tornillos, tapas o caja. 2. No exponer el aparato a la lluvia ni a la hœmedad. Precauci-n: Ventilaci-n Adecuada Para evitar el riesgo de choque elŽctrico e incendio y para proteger el aparato contra da–os. Ubique el aparato de la siguiente manera: Frente: Espacio abierto sin obstrucciones Lados: 3 cm sin obstrucciones a los lados Parte superior: 5 cm sin obstrucciones en la parte superior Parte trasera: 15 cm sin obstrucciones en la parte trasera Fondo: Sin obstrucciones, col-quelo sobre una superficie nivelada Stand height 5cm or more Allura del soporte 5 cm o m‡s 1. PRODUCTO LçSER DE CLASE 1 2.PELIGRO: Radiaci-n l‡ser visible cuando se abra un sistema de bloqueo defectuoso o averiado. Evitar la exposici-n directa al haz. 3.PRECAUCIîN: No abrir la tapa superior. No hay piezas reparables por el usuario en el interior de la unidad; deje todo mantenimiento o reparaci-n al personal tŽcnico cualificado.
Page 2
1 Table of Contents Getting Started ........................................................................................... 2 Important cautions ........................................................................ 2 Safety precautions ......................................................................... 2 Checking the supplied accessories ................................................ 2 System outline ............................................................................................ 3 Installation .................................................................................................. 4 To attach non-slip rubbers to the center speaker ........................... 4 To hang satellite speakers from the wall ....................................... 4 About discs ................................................................................................. 5 Playable disc types ........................................................................ 5 Disc structure ................................................................................ 5 Video CDs or SVCDs with Playback Control function ................ 5 Connections ................................................................................................ 6 Connecting the FM and AM antennas .......................................... 6 To connect the powered sub woofer ............................................. 6 Connecting the TV ........................................................................ 6 VIDEO OUT SELECT ................................................................. 7 To connect speakers ...................................................................... 7 Connecting Audio/Video Components ......................................... 8 Connecting the power cord ......................................................... 10 Putting batteries in the remote control ........................................ 10 Parts Identification .................................................................................. 11 Principles of operation ........................................................................... 13 Operation with the remote control .............................................. 13 To operate via the on-screen menu ............................................. 14 Preventing screen burn-out with the screen saver [SCREEN SAVER] ................................................................. 15 Basic operations ...................................................................................... 16 To turn the system power supply ON and OFF (standby) .......... 16 To turn TV power ON and OFF .................................................. 16 Adjusting volume ........................................................................ 16 Muting the sound ........................................................................ 17 Selecting the source to play ........................................................ 17 Changing the source name .......................................................... 17 Selecting the analog or digital input mode ................................. 18 Changing the decode mode ......................................................... 18 Adjusting the Input Signal Level ................................................ 19 Sub woofer volume control and phase setting ............................ 19 Audio channel display lamp ....................................................... 19 Using the Sleep Timer ................................................................ 20 Using the DSP Modes ................................................................. 20 Using the DVD player .............................................................................. 22 To play a disc .............................................................................. 22 Pausing ........................................................................................ 23 Fast forward and rewind ............................................................. 23 Locating the beginning ............................................................... 23 Resuming playback ..................................................................... 24 Selecting playback from the DVD menu .................................... 24 Selecting the location to view from the video CD menu ............ 25 To specify the title or track number for playback ....................... 25 To play from the beginning of a title, chapter, or track .............. 26 To specify the chapter number for playback [CHAP. SEARCH] .. 26 To specify the time for playback [TIME SEARCH] .................. 26 To select the screen for playback from the digest screen [DIGEST] ................................................................................ 27 To advance the picture one frame at a time ................................ 28 Slow-Motion Playback [SLOW] ................................................. 28 To display Continuous Photos [STROBE] ................................. 28 Zooming a scene [ZOOM] .......................................................... 29 Changing the Subtitle Language [SUB TITILE] ........................ 29 Changing the audio language or sound [AUDIO] ...................... 30 Changing the audio channel [AUDIO] ....................................... 30 Viewing from Multiple Angles [ANGLE] .................................. 31Selecting the Picture Character [THEATER POSITION] .......... 32 Repeating a current title, chapter or track, or all tracks [REPEAT] ............................................................................... 32 Repeating a desired part [A-B REPEAT] ................................... 33 Sampling all tracks [INTRO] ...................................................... 33 Checking the Disc Time [TIME SELECT] ................................ 34 Programming the Playing Order of the Tracks [PROGRAM] .... 34 Random Play [RANDOM] ......................................................... 35 Receiving radio broadcasts ................................................................... 36 Setting the AM tuner interval spacing ........................................ 36 Tuning in stations manually ........................................................ 36 Using preset tuning ..................................................................... 36 Selecting the FM reception mode ............................................... 37 Beat cut ....................................................................................... 37 Performing miscellaneous settings ..................................................... 38 AV amplifier settings on-screen display ..................................... 38 DVD settings on-screen display ................................................. 38 MAIN MENU Settings ............................................................................. 39 Opening the MAIN MENU ........................................................ 39 ON SCREEN LANGUAGE ....................................................... 39 Setting the SLEEP TIMER ......................................................... 39 Changing the DECODE MODE ................................................. 40 Changing the DSP MODE .......................................................... 40 Adjusting the volume .................................................................. 40 SOUND MENU Settings .......................................................................... 41 Opening the SOUND MENU ..................................................... 41 Adjusting the balance ................................................................. 41 Using LOUDNESS ..................................................................... 41 Adjusting input signal ................................................................. 42 Adjusting the sub-woofer output level ........................................ 42 Adjusting the dynamic range ...................................................... 42 Adjusting the DSP effect ............................................................ 42 SPEAKER MENU Settings ....................................................................... 43 Opening the SPEAKER MENU ................................................. 43 Switching speaker mode ............................................................. 43 Playing a test tone ....................................................................... 44 Setting speaker size ..................................................................... 44 Setting speaker level ................................................................... 45 Adjusting delay time ................................................................... 45 DVD MENU Settings ................................................................................ 46 Opening the DVD MENU .......................................................... 46 Choosing menu language ............................................................ 46 Choosing audio language ............................................................ 47 Choosing subtitle language ......................................................... 47 On-screen guide settings ............................................................. 47 Select monitor type ..................................................................... 48 Screen saver settings ................................................................... 48 Limiting playback by children ............................................................... 49 To set Parental Lock for the first time [PARENTAL LOCK] ..... 49 To temporarily release the Parental lock ..................................... 50 Care and handling of discs .................................................................... 51 How to handle discs .................................................................... 51 AV COMPU LINK Remote Control System ............................................ 52 COMPU LINK Remote Control System .................................................. 54 Operating JVCÕs Audio/Video Components ......................................... 55 Operating Other ManufacturersÕ Video Equipment ........................... 57 Troubleshooting ........................................................................................ 59 Specifications .......................................................................................... 60 Appendix A: Table of languages and their abbreviations ................ 61 Appendix B: Country code list for parental lock ................................ 62 p01-7/TH-A10[2/3U]1/f00.9.18, 10:21 PM 1
Page 4
3 System outline This system consists of the center unit containing a DVD player, a radio, and a pre-amp, as well as the powered sub woofer, the center speaker, and four satellite speaker units. It provides a fully functional DVD theater system by simply connecting to a TV set. Center speaker (SP-XCA10) Satellite speaker (SP-XSA10) Satellite speaker (SP-XSA10)Satellite speaker (SP-XSA10) Satellite speaker (SP-XSA10) The center speaker and the satellite speakers are connected to the powered sub-woofer.The center unit and powered sub woofer are connected with the system cable. The TV is connected to the center unit. Contains a DVD player, radio, and preamp (volume control, tone control), together with a Dolby digital decoder, DTS digital surround decoder and MPEG Multichannel decoder for Dolby Surround, DTS Digital Surround and MPEG Multichannel Surround effects. For some music software, the DAP mode offers the expanded sound field. This system is capable of most operations. As it is illuminated it may also be used in the dark. It may also be used to operate JVC TVs, VCRs, MD recorders, and cassette decks, as well as TVs and VCRs from other manufacturers. Note that the remote control unit must be programmed with the correct settings when using products from other manufacturers. Only the most commonly used functions for this system are available.TV Center unit (XV-THA10) Powerd sub woofer (SP-PWA10) Front left speaker Front right speaker Rear right speaker Rear left speaker p01-7/TH-A10[2/3U]1/f00.9.18, 10:21 PM 3
