RX-DP10VBK/RX-DP1OVSL
RX-DP10RSL

-Safety Precautions

1. This design of this product contains special hardware and many circuits and components specially for safety
purposes. For continued protection, no changes should be made to the original design unless authorized in
writing by the manufacturer. Replacement parts must be identical to those used in the original circuits. Services
should be performed by qualified personnel only.

2. Alterations of the design or circuitry of the product should not be made. Any design alterations of the product
should not be made. Any design alterations or additions will void the manufacturer's warranty and will further
relieve the manufacture of responsibility for personal injury or property damage resulting therefrom.

3. Many electrical and mechanical parts in the products have special safety»related characteristics. These
characteristics are often not evident from visual inspection nor can the protection afforded by them necessarily
be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which
have these special safety characteristics are identified in the Parts List of Service Manual. Electrical
components having such features are identified by shading on the schematics and by (/i\) on the Parts List in
the Service Manual. The use of a substitute replacement which does not have the same safety characteristics
as the recommended replacement parts shown in the Parts List of Service Manual may create shock, fire, or
other hazards.

4. The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the like to be
separated from live parts, high temperature parts, moving parts and/or sharp edges for the prevention of
electric shock and fire hazard. When service is required, the original lead routing and dress should be
observed, and it should be confirmed that they have been returned to normal, after re-assembling.

5. Leakage current check (Electrical shock hazard testing)

After reassembling the product, always perform an isolation check on the exposed metal parts of the product

(antenna terminals, knobs, metal cabinet, screw heads, headphone jack, control shafts, etc.) to be sure the

product is safe to operate without danger of electrical shock.

Do not use a line isolation transformer during this check.

0 Plug the AC line cord directly into the AC outlet. Using a "Leakage Current Tester", measure the leakage
current from each exposed metal parts of the cabinet, particularly any exposed metal part having a return
path to the chassis, to a known good earth ground. Any leakage current must not exceed 0.5mA AC (r.m.s.).

0 Alternate check method
Plug the AC line cord directly into the AC outlet. Use an AC voltmeter having, 1,000 ohms per volt or more
sensitivity in the following manner. Connect a 1,500 Q10W resistor paralleled by a 0.15M F AC-type capacitor

between an exposed metal part and a known good earth ground. AC VOLTMETER
Measure the AC voltage across the resistor with the AC a (Having1000
voltmeter. ohms/volts, .. .
Move the resistor connection to each exposed metal part, c °m°e sens'mml)

particularly any exposed metal part having a return path to
the chassis, and measure the AC voltage across the resistor.

0.1511 F AC TYPE

Now, reverse the plug in the AC outlet and repeat each -"| Placeihis
measurement. Voltage measured any must not exceed 0.75 V W . e :géfieeigosed
AC (r.m.s.). This corresponds to 0.5 mA AC (r.m.s.). 15009 10W metal part.
Good earth ground
-Warning A CAUTION

1.This equipment has been designed and manufactured to meet international safety standards.
2. It is the legal responsibility of the repairer to ensure that these safety standards are maintained.
3. Repairs must be made in accordance with the relevant safety standards.

4. It is essential that safety critical components are replaced by approved parts.

5. If mains voltage selector is provided, check setting for local voltage.

Burrs formed during molding may
be left over on some parts of the
chassis. Therefore, pay attention to
such burrs in the case of
preforming repair of this system.

In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the
parts that are printed over with black such as the resistor (-), diode (h) and ICP (Q) or identified by the "A"
mark nearby are critical for safety.

When replacing them, be sure to use the parts of the same type and rating as specified by the manufacturer.
(Except the J&C version)

Page 6

RX-DP10VBK/RX-DP10VSL

RX-DP10RSL
I R ' th I s Fi 4) CN983 . .
emovmg e rear pane ( ee 9' CN977 Plastlc rlvet
~ Prior to performing the following procedure, remove _ ' CN981
the top cover. Plastic rivet S stem control board

I Removing the system control board power/ fuse

1. Disconnect the card wires and harness from

1. Remove the power cord stopper from the rear panel
by moving it in the direction of the arrow.

2. Remove the thirty six (B/E/EN version is thirty two)
screws E attaching the each boards to the rear panel
on the back of the body.

3. Remove the thirteen screws F attaching the rear Fig.5
panel on the back of the body and bottom.

CN25 Audio signal 1 board

(See Fig.5 and 6) board

- Prior to performing the following procedure, remove
the top cover and front panel assembly.

connector CN963, CN964 and CN981 on the system .
Tie band

control board. Tie band
CN208
2. Cut off the tie bands fixing the harnesses. I t WC only)
: . -TIe band

3. Disconnect the harness from connector CN43 on the CN43-XI»
4. Disconnect the connector CN324 on the audio signal power supply 2 board N

5. Remove the three plastic rivet. CN631

l Removing the DSP board

1-6

power supply 2 board and CN25 on the power/ fuse
board.

2 board and CN205, CN234, CN208(J/C only) on the
audio signal 1 board.

Plastic rivet

(See Fig.6 and 7)
- Prior to performing the following procedure, remove
the top cover and the rear panel.

1. Disconnect the connector CN631 on the DSP board.

2. Disconnect the connector CN203 on the audio signal
1 board.

3. Removing the two plastic rivet and disconnect the
connector CN633 on the DSP board.

I Removing the shield cover (See Fig.8)

- Prior to performing the following procedure, remove

the top cover and the rear panel. / .
Shield cover

1. Removing the screw G attaching the shield cover.

2. Shift the shield cover before, and pull upward. Fig.8
