Jvc RX 5020 VBK Owners Manual
This is the 72 pages manual for Jvc RX 5020 VBK Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Jvc RX 5020 VBK Owners Manual (Ocr-read)
Page 1
Caution: Proper Ventilation To avoid risk of electric shock and fire and to protect from damage. Locate the apparatus as follows: Front: No obstructions open spacing. Sides: No obstructions in 10 cm from the sides. Top: No obstructions in 10 cm from the top. Back: No obstructions in 15 cm from the back. Bottom: No obstructions, place on the level surface. In addition, maintain the best possible air circulation as illustrated. Attention: Ventilation Correcte Pour éviter les chocs électriques, lincendie et tout autre dé\ gât. Disposer lappareil en tenant compte des impératifs suivants Avant: Rien ne doit gêner le dégagement Flancs: Laisser 10 cm de dégagement latéral Dessus: Laisser 10 cm de dégagement supérieur Arrière: Laisser 15 cm de dégagement arrière Dessous: Rien ne doit obstruer par dessous; poser lappareil sur unesurface plate. Veiller également à ce que lair circule le mieux possible comm\ e illustré. Floor Plancher Stand height 15 cm or more Hauteur du socle: 15 cm ou plus Front Avant Spacing 15 cm or more Dégagement de 15 cm ou plus Wall or obstructions Mur, ou obstruction CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. CAUTION Caution –– STANDBY/ON button! Disconnect the mains plug to shut the power off completely. The STANDBY/ON button in any position does not disconnect the mains line. The power can be remote controlled. Attention –– Commutateur STANDBY/ON ! Déconnecter la fiche de secteur pour couper complètement le courant. Le commutateur STANDBY/ON ne coupe jamais complètement la ligne de secteur, quelle que soit sa position. Le courant peut être télécommandé. CAUTION To reduce the risk of electrical shocks, fire, etc.: 1. Do not remove screws, covers or cabinet. 2. Do not expose this appliance to rain or moisture. ATTENTION Afin déviter tout risque délectrocution, dincendie, etc.: 1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir lecoffret de lappareil. 2. Ne pas exposer l appareil à la pluie ni à lhumidité. Warnings, Cautions and Others/ Mises en garde, précautions et indications diverses RX-5020VBK RX-5022VSL WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. For the main unit:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does caus\ e harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the manufacturer for compliance could void the user s authority to operate the equipment. For Canada/pour le Canada CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQUAU FOND For Canada/pour Le Canada THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING EQUIPMENT STANDARD ENTITLED DIGITAL APPARATUS, ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS. CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE BRUITS RADIOELECTRIQUES APPLICABLES AUX APPAREILS NUMERIQUES DE CLASSE B PRESCRITES DANS LA NORME SUR LE MATERIEL BROUILLEUR; APPAREILS NUMERIQUES, NMB-003 EDICTEE PAR LE MINISTRE DES COMMUNICATIONS.
Page 2
1 Table of Contents Parts Identification ...................................... 2 Getting Started ........................................... 3 Before Installation ...................................................................... 3 Checking the Supplied Accessories ........................................... 3 Putting Batteries in the Remote Control .................................... 3 Connecting the FM and AM Antennas ....................................... 4 Connecting the Speakers ............................................................ 5 Connecting Audio/Video Components ....................................... 6 Connecting the Power Cord ....................................................... 7 Basic Operations ......................................... 8 Turning On the Power ................................................................ 8 Selecting the Source to Play ....................................................... 8 Adjusting the Volume ................................................................. 9 Listening Only with Headphones ............................................... 9 Turning Off the Sounds Temporarily-Muting ........................ 10 Turning Off the Power with the Sleep Timer ........................... 10 Basic Settings ........................................... 11 Setting the Digital Input (DIGITAL IN) Terminals ................. 11 Selecting the Analog or Digital Input Mode ............................ 11 Setting the Speaker Information ............................................... 12 Sound Adjustments .................................... 15 Attenuating the Input Signal .................................................... 15 Adjusting the Front Speakers Output Balance ......................... 15 Adjusting the Tone ................................................................... 15 Adjusting the Subwoofer Output Level .................................... 15 Tuner Operations ....................................... 16 Tuning in Stations Manually .................................................... 16 Using Preset Tuning ................................................................. 16 Selecting the FM Reception Mode ........................................... 17 Creating Realistic Sound Fields ................... 18 About Relations between Speaker Layout andSurround Modes ................................................................. 20 Using Dolby Pro Logic II, Dolby Digital and DTS Digital Surround ........................................................ 21 Using DAP Modes and All Channel Stereo ............................. 23 COMPU LINK Remote Control System ......... 24 Operating JVC's Audio/Video Components .......................................... 25 Operating Audio Components .................................................. 25 Operating Video Components .................................................. 27 Operating Other Manufacturers' VideoEquipment ............................................ 28 Troubleshooting ......................................... 30 Specifications ............................................ 31 This mark indicates that the remote control CANNOT be used for the operation explained. Use buttons on the front panel. This mark indicates that the remote control CAN ONLY be used for the operation explained. Remote ONLY Table of Contents Remote NOT
Page 40
