In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the
parts that are printed over with black such as the resistor (I), diode (-) and ICP (.) or identified by the "a:
mark nearby are critical for safety.
Page 11
I FL board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)
@ o
GVA10162-A2 32;. O
I Volume board Lead free solder used in the board (material : Sn-Ag-Cu, melting point: 219 Centigrade)|
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)|
W 843 @«E
@
I AUX jack board
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)|
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)|
I Headphone jack board
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)|
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)|
GVA10162-A5
