Jvc MXKA 5 Service Manual

This is the 16 pages manual for Jvc MXKA 5 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 16
Jvc MXKA 5 Service Manual

Extracted text from Jvc MXKA 5 Service Manual (Ocr-read)

Page 2

MX-KA5

In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the
parts that are printed over with black such as the resistor (I), diode (h) and ICP (.) or identified by the "A"

mark nearby are critical for safety.
(This regulation does not correspond to J and C version.)
