Page 1
1-2 (No.MA492)
SPECIFICATION
- Subject to change without notice.
- If a kit is necessary for your car, consult your telephone directory for the nearest car audio speciality shop.
KD-A725/KD-R720/KD-S48/KD-S88BT
AUDIO AMPLIFIER SECTION
Power Output 20 W RMS × 4 Channels at 4 Ω and ≤ 1% THD+N
Signal-to-Noise Ratio 80 dBA (reference: 1 W into 4 Ω)
Load Impedance 4 Ω (4 Ω to 8 Ω allowance)
Frequency Response 40 Hz to 20 000 Hz
Line-Out or Subwoofer-Out Level / Impedance 2.5 V/20 kΩ load (full scale)
Output Impedance≤ 600 Ω
Other Terminal
AUX (auxiliary) input jack, USB input terminal, USB rear cable, Expansion port, Antenna terminal
TUNER SECTION
Frequency Range FM with channel interval set to 200 kHz 87.9 MHz to 107.9 MHz
50 kHz 87.5 MHz to 108.0 MHz
AM with channel interval set to
10 kHz 530 kHz to 1 700 kHz
9 kHz 531 kHz to 1 611 kHz
FM Tuner Usable Sensitivity 9.3 dBf (0.8 µV/75Ω)
50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation: 40 dB
AM Tuner Sensitivity/Selectivity 20 µV/40 dB
CD PLAYER SECTION
Type Compact disc player
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of Channels 2 channels (stereo)
Frequency Response 5 Hz to 20 000 Hz
Signal-to-Noise Ratio 98 dB
102 dB (For KD-S48)
Wow and Flutter Less than measurable limit
MP3 Decoding Format (MPEG1/2 Audio Layer 3) Max. Bit Rate 320 kbps
WMA (Windows Media (R) Audio) Decoding Format Max. Bit Rate 320 kbps
USB SECTION
USB Standard USB 1.1, USB 2.0
Data Transfer Rate (Full Speed) Max. 12 Mbps
Compatible Device Mass Storage Class (except HDD)
Compatible File System FAT 32/ 16/ 12
Playable Audio Format MP3/ WMA/ WAV
Max. Current DC 5 V 1 A
Output Power (For KD-S48) DC 5 V 1 A , USB input terminal (front/rear)
BLUETOOTH SECTION
Version Bluetooth 2.1 certified (+EDR)
Profile HFP 1.5, OPP 1.1, A2DP 1.2, AVRCP 1.3, PBAP 1.0
GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0°C to +40°C (32°F to 104°F)
Dimensions (W× H × D) : (approx.) Installation Size 182 mm × 52 mm × 158 mm (7-3/16 × 2-1/16 × 6-1/4)
Panel Size 188 mm × 59 mm × 9 mm (7-7/16 × 2-3/8 × 3/8)
Mass 1.3 kg (2.9 lbs) (excluding accessories)
Page 2
(No.MA492)1-3 -
Subject to change without notice.
KD-R721BT, KD-R727BT, KD-R729BT
AUDIO AMPLIFIER SECTION
Maximum Power Output 50 W per channel
Continuous Power Output (RMS)
20 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 1% total harmonic distortion.
Signal-to-Noise Ratio 70 dB
Load Impedance 4 Ω (4 Ω to 8 Ω allowance)
Frequency Response 40 Hz to 20 000 Hz
Line-Out or Subwoofer-Out Level / Impedance 2.5 V/20 kΩ load (full scale)
Output Impedance≤ 600 Ω
Other Terminal
USB input terminal, USB rear cable, Auxiliary input jack, Antenna input
TUNER SECTION
Frequency Range FM 87.5 MHz to 108.0 MHz
LW [For KD-R727] 65.0 MHz to 74.0 MHz
AM MW 531 kHz to 1 611 kHz
LW 153 kHz to 279 kHz
FM Tuner Usable Sensitivity 9.3 dBf (0.8 µV/75Ω)
50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation: 40 dB
MW Tuner Sensitivity/Selectivity 20 µV/40 dB
LW Tuner Sensitivity 50 µV
CD PLAYER SECTION
Type Compact disc player
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of Channels 2 channels (stereo)
Frequency Response 5 Hz to 20 000 Hz
Signal-to-Noise Ratio 102 dB
Wow and Flutter Less than measurable limit
MP3 Decoding Format (MPEG1/2 Audio Layer 3) Max. Bit Rate: 320 kbps
WMA (Windows Media (R) Audio) Decoding Format Max. Bit Rate: 192 kbps
USB SECTION
USB Standard USB 1.1, USB 2.0
Data Transfer Rate (Full Speed) Max. 12 Mbps
Compatible Device Mass Storage Class (except HDD)
Compatible File System FAT 32/ 16/ 12
Playable Audio Format MP3/ WMA/ WAV
Output Power DC 5 V 1 A, USB input terminal (front/rear)
BLUETOOTH SECTION
Version Bluetooth 2.1 certified (+EDR)
Power Class Class 2 Radio
Service Area 10 m
Profile HFP 1.5, OPP 1.1, A2DP 1.2, AVRCP 1.3, PBAP 1.0
GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0°C to +40°C
Dimensions (W× H × D) : (approx.) Installation Size 182 mm × 52 mm × 158 mm
Panel Size 188 mm × 59 mm × 9 mm
Mass 1.3 kg (excluding accessories)
