Jvc KDS 821 R Service Manual 2
This is the 50 pages manual for Jvc KDS 821 R Service Manual 2.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Jvc KDS 821 R Service Manual 2 (Ocr-read)
Page 1
JVB
SERVICE MANUAL
CD RECEIVER
KD-3821 R
R-D-S
Contents
Safety precaution ----------------- 1»2
Preventing static electricity ----- 1~3
Disassembly method ------------ 1-4
Adjustment method -------------- 1-1 1
COMPACT
@USIE
DIGITAL AUDIO
KD-S821 R
Area Suffix
E -------- Continental Europe
EX ------ Central Europe
Flow of functional
operation unit TOC read -----
Maintenance of laser pickup
Replacement of laser pickup
Description of major le ----------
2-1
2-3
2-3
2-6
COPYRIGHT (2;) 2002 VICTOR COMPANY OF JAPAN, LTD.
No.49679
Feb. 2002
Page 2
KD-S821 R
Safety precaution
A CAUTION Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
A CAUTION Please use enough caution not to see the beam directly or touch it in case of an
adjustment or operation check.
1-2
