Jvc KDR 707 EE Service Manual
This is the 53 pages manual for Jvc KDR 707 EE Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Jvc KDR 707 EE Service Manual (Ocr-read)
Page 1
JVB
SERVICE MANUAL
CD RECEIVER
KD-R701 E, KD-R701 EX, KD-R701EY,
KD-R701EU, KD-R705U, KD-R705UN,
KD-R705UT, KD-R705UH, KD-R707EE
cept KD R705)
Radio Data System
w I ©iPod DiPhone
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)
TAB LE OF CONTENTS
1 PRECAUTION ......................................................................... 1-6
2 SPECIFIC SERVICE INSTRUCTIONS ...................................................... 1-9
3 DISASSEMBLY ....................................................................... 1-9
4 ADJUSTMENT ....................................................................... 1-18
5 TROUBLESHOOTING ................................................................. 1-24
COPYRIGHT © 2009 Victor Company of Japan, Limited N0.MA445
2009/3
