Page 1
1-2 (No.MA377)
SPECIFICATION
KD-G441/KD-G351
Design and specifications are subject to change without notice.AUDIO AMPLIFIER SECTION
Maximum Power Output Front/Rear 50 W per channel
Continuous Power Output (RMS) Front/Rear 19 W per channel into 4 Ω 40 Hz to 20 000 Hz at no
more than 0.8% total harmonic distortion
Load Impedance 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Range Bass ±12 dB at 60 Hz
Middle ±12 dB at 1 kHz
Treble ±12 dB at 10 kHz
Frequency Response 40 Hz to 20 000 Hz
Signal to Noise Ratio 70 dB
Audio Output Level (for KD-G441) Line-Out Level/Impedance 2.5 V/20 kΩ load (full scale)
Output Impedance 1 kΩ
Subwoofer-Out Level/Impedance 2.5 V /20 kΩ load (full scale)
Other Terminals AUX (auxiliary) input jack USB input jack Steering wheel remote input (forKD-G441)
TUNER SECTION
Frequency Range FM 87.5 MHz to 108.0 MHz
AM MW: 522 kHz to 1 620 kHz
LW: 144 kHz to 279 kHz
FM Tuner Usable Sensitivity 11.3 dBf (1.0 µV/75 Ω)
50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 30 dB
MW Tuner Sensitivity/Selectivity 20 µV/35 dB
LW Tuner Sensitivity 50 µV
CD PLAYER SECTION
Type Compact disc player
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of Channels 2 channels (stereo)
Frequency Response 5 Hz to 20 000 Hz
Dynamic Range 96 dB
Signal-to-Noise Ratio 98 dB
Wow and Flutter Less than measurable limit
MP3 Decoding Format: (MPEG1/2 Audio Layer 3) Max. Bit Rate 320 kbps
WMA (Windows Media® Audio) Decoding Format Max. Bit Rate 320 kbps
USB SECTION
USB Standard USB 1.1, USB 2.0
Data Transfer Rate (Full Speed) Max. 12 Mbps
Storage Less than 8 GB (1 partition type)
Compatible Device Mass storage class (except HDD)
Compatible File System FAT 32/16/12
Playable Audio Format MP3/WMA
Max. Current 500 mA
GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0°C to +40°C
Dimensions (W × H × D) Installation Size (approx.) 182 mm × 52 mm × 160 mm
Panel Size (approx.) 188 mm × 58 mm × 13 mm
Mass (approx.) 1.3 kg (excluding accessories)
Page 2
(No.MA377)1-3 KD-G447/KD-G357
Design and specifications are subject to change without notice.AUDIO AMPLIFIER SECTION
Maximum Power Output Front/Rear 50 W per channel
Continuous Power Output (RMS) Front/Rear 19 W per channel into 4 Ω 40 Hz to 20 000 Hz at no
more than 0.8% total harmonic distortion
Load Impedance 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Range Bass ±12 dB at 60 Hz
Middle ±12 dB at 1 kHz
Treble ±12 dB at 10 kHz
Frequency Response 40 Hz to 20 000 Hz
Signal to Noise Ratio 70 dB
Other Terminals AUX (auxiliary) input jack, USB input jack
TUNER SECTION
Frequency Range FM1/FM2 87.5 MHz to 108.0 MHz
FM3 65.00 MHz to 74.00 MHZ
AM MW: 522 kHz to 1 620 kHz
LW: 144 kHz to 279 kHz
FM Tuner Usable Sensitivity 11.3 dBf (1.0 µV/75 Ω)
50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 30 dB
MW Tuner Sensitivity/Selectivity 20 µV/35 dB
LW Tuner Sensitivity 50 µV
CD PLAYER SECTION
Type Compact disc player
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of Channels 2 channels (stereo)
Frequency Response 5 Hz to 20 000 Hz
Dynamic Range 96 dB
Signal-to-Noise Ratio 98 dB
Wow and Flutter Less than measurable limit
MP3 Decoding Format: (MPEG1/2 Audio Layer 3) Max. Bit Rate 320 kbps
WMA (Windows Media® Audio) Decoding Format Max. Bit Rate 320 kbps
USB SECTION
USB Standard USB 1.1, USB 2.0
Data Transfer Rate (Full Speed) Max. 12 Mbps
Storage Less than 8 GB (1 partition type)
Compatible Device Mass storage class (except HDD)
Compatible File System FAT 32/16/12
Playable Audio Format MP3/WMA
Max. Current 500 mA
GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0°C to +40°C
Dimensions (W × H × D) Installation Size (approx.) 182 mm × 52 mm × 160 mm
Panel Size (approx.) 188 mm × 58 mm × 13 mm
Mass (approx.) 1.3 kg (excluding accessories)
Page 16
(No.MA377)1-17 3.2.5 Removing the clamper assembly
(See Figs.7 and 8)
- Remove the top cover.
Move the clamper assembly in the direction of the arrow to release
the joints f from the chassis unit.
Fig.7
Fig.8
f f
Clamper assembly
Chassis unit
f
f Clamper assembly
Chassis unit
