Page 1
1-2 (No.MA372)
SPECIFICATION
KD-G140/KD-G240
Design and specifications are subject to change without notice.Audio amplifier section
Power Output 20 W RMS × 4 Channels at 4 Ω and < or = 1% THD+N
Signal to Noise Ratio 80 dBA (reference: 1 W into 4 Ω)
Load Impedance 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Range Bass ±12 dB at 60 Hz
Mid-range ±12 dB at 1 kHz
Treble ±12 dB at 7.5 kHz
Frequency Response 40 Hz to 20 000 Hz
Line-Out Level/Impedance 2.5 V/20 kΩ load (full scale)
Output Impedance 1 kΩ
Subwoofer-Out Level/Impedance 2.5 V/20 kΩ load (full scale)
Tuner section
Frequency Range FM 87.5 MHz to 107.9 MHz (with channel interval set to 100 kHz or 200 kHz)
87.5 MHz to 108.0 MHz (with channel interval set to 50 kHz)
AM 530 kHz to 1 710 kHz (with channel interval set to 10 kHz)
531 kHz to 1 602 kHz (with channel interval set to 9 kHz)
FM Tuner Usable Sensitivity 11.3 dBf (1.0 µV/75 Ω)
50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)
Alternate Channel Selectivity
(400 kHz)65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 35 dB
AM Tuner Sensitivity/Selectivity 20 µV/35 dB
CD player section
Type Compact disc player
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of channels 2 channels (stereo)
Frequency Response 5 Hz to 20 000 Hz
Dynamic Range 93 dB
Signal-to-Noise Ratio 98 dB
Wow and Flutter Less than measurable limit
MP3 Decoding Format
(for KD-G240) Max. Bit RateMPEG1/2 Audio Layer 3
320 kbps
WMA (Windows Media®
Audio) Decoding Format
(for KD-G240)Max. Bit Rate 192 kbps
General
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0°C to +40°C (32°F to 104°F)
Dimensions (W × H × D) Installation Size (approx.) 182 mm × 52 mm × 160 mm (7-3/16 × 2-1/16 × 6-5/16)
Panel Size (approx.) 188 mm × 58 mm × 5 mm (7-7/16 × 2-5/16 × 1/4)
Mass (approx.) 1.3 kg (2.9 lbs) (excluding accessories)
Page 2
(No.MA372)1-3 KD-G244/KD-G245/KD-G248/KD-G394/KD-G395/KD-G396/KD-G398
Design and specifications are subject to change without notice.Audio amplifier section
Maximum Power Output: Front/Rear 50 W per channel
Continuous Power Output (RMS): Front/Rear 19 W per channel into 4 Ω 40 Hz to 20 000 Hz at no more than 0.8%
total harmonic distortion.
Load Impedance 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Range Bass ±12 dB at 60 Hz
Mid-range ±12 dB at 1 kHz
Treble ±12 dB at 7.5 kHz
Frequency Response 40 Hz to 20 000 Hz
Signal-to-Noise Ratio 70 dB
Line-Out Level/Impedance (for KD-G395/KD-G396/KD-G398) 2.5 V/20 kΩ load (full scale)
Output Impedance (for KD-G395/KD-G396/KD-G398) 1 kΩ
Other Terminal (except for KD-G248/KD-G398) AUX (auxiliary) input jack
Tuner section
Frequency Range FM 87.5 MHz to 108.0 MHz
AM 531 kHz to 1 602 kHz
FM Tuner Usable Sensitivity 11.3 dBf (1.0 µV/75 Ω)
50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)
Alternate Channel Selectivity
(400 kHz)65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation (for KD-G244/KD-G394) 35 dB
(for others) 30 dB
AM Tuner Sensitivity/Selectivity 20 µV/35 dB
CD player section
Type Compact disc player
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of channels 2 channels (stereo)
Frequency Response 5 Hz to 20 000 Hz
Dynamic Range 93 dB
Signal-to-Noise Ratio 98 dB
Wow and Flutter Less than measurable limit
MP3 Decoding Format (MPEG1/
2 Audio Layer 3) (for KD-G395/
KD-G396/KD-G398)Max. Bit Rate 320 kbps
WMA (Windows Media® Audio)
Decoding Format (for KD-G395/
KD-G396/KD-G398)Max. Bit Rate 192 kbps
General
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0°C to +40°C
Dimensions (W × H × D) Installation Size (approx.) 182 mm × 52 mm × 160 mm
Panel Size (approx.) 188 mm × 58 mm × 5 mm
Mass (approx.) 1.3 kg (excluding accessories)
