Extracted text from Jvc KD R852BT Owners Manual (Ocr-read)
Page 1
i Information on Disposal of Old Electrical and Electronic Equipment and B\ atteries (applicable for EU countries that have adopted separate waste collection systems) Products and batteries with the symbol (crossed-out wheeled bin) canno\ t be disposed as household waste. Old electrical and electronic equipment and batteries should be recycled\ at a facility capable of handling these items and their waste byproducts. Contact your local authority for details in locating a recycle facility \ nearest to you. Proper recycling and waste disposal will help conserve resources whilst preventing detrim\ ental effects on our health and the environment. Notice: The sign Pb below the symbol for batteries indicates tha\ t this battery contains lead. Information sur lélimination des anciens équipements électr\ iques et électroniques et piles électriques (applicable dans les pays de lUnion Européenne qu\ i ont adopté des systèmes de collecte sélective) Les produits et piles électriques sur lesquels le pictogramme (poube\ lle barrée) est apposé ne peuvent pas être éliminés comme ordures ménagères. Les anciens équipements électriques et électroniques et piles é\ lectriques doivent être recyclés sur des sites capables de traiter ces produits et leurs déchets. Contactez vos autorités locales pour connaître le site de recyclag\ e le plus proche. Un recyclage adapté et lélimination des déchets aideront à conserver \ les ressources et à nous préserver des leurs effets nocifs sur notre santé et sur lenvironnement. Remarque: Le symbole Pb ci-dessous sur des piles électrique i\ ndique que cette pile contient du plomb. For Israel The marking of products using lasers The label is attached to the chassis/case and says that the component us\ es laser beams that have been classified as Class 1. It means that the unit is utilizing laser beams that are of \ a weaker class. There is no danger of hazardous radiation outside the unit. Marquage des produits utilisant un laser Létiquette est attachée au châssis/boîtier de lappar\ eil et indique que lappareil utilise des rayons laser de classe 1. Cela signifie que lappareil utilise des rayons laser d\ une classe faible. Il ny a pas de danger de radiation accidentelle hors de lappareil. Declaration of Conformity with regard to the R&TTE Directive 1999/5/EC Declaration of Conformity with regard to the EMC Directive 2004/108/EC Declaration of Conformity with regard to the RoHS Directive 2011/65/EU Manufacturer: JVC KENWOOD Corporation 3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, Japan EU Representative: JVC Technical Services Europe GmbH Konrad-Adenauer-Allee 1-11, D-61118 Bad Vilbel, Germany Déclaration de conformité vis à vis de la Directive 1999/5/CE d\ e R&TTE Déclaration de conformité se rapportant à la directive EMC 2004\ /108/EC Déclaration de conformité se rapportant à la directive RoHS 201\ 1/65/EU Fabricant: JVC KENWOOD Corporation 3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, Japan Représentants dans lUE: JVC Technical Services Europe GmbH Konrad-Adenauer-Allee 1-11, D-61118 Bad Vilbel, Germany
Page 2
ii English Hereby, JVC KENWOOD declares that this unit KD-R951BT/KD-R852BT/KD-R851BT is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Français Par la présente JVC KENWOOD déclare que lappareil KD-R951BT/KD-R852BT/KD-R851BT est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Par la présente, JVC KENWOOD déclare que ce KD-R951BT/KD-R852BT/KD-R851BT est conforme aux exigences essentielles et aux autres dispositions de la directive 1999/5/CE qui lui sont applicables. Deutsch Hiermit erklärt JVC KENWOOD, dass sich dieser KD-R951BT/KD-R852BT/KD-R851BT in Übereinstimmung mit den grundlegenden Anforderungen und den anderen relevanten Vorschriften der Richtlinie 1999/5/EG befindet. (BMWi) Hiermit erklärt JVC KENWOOD die Übereinstimmung des Gerätes KD-R951BT/ KD-R852BT/KD-R851BT mit den grundlegenden Anforderungen und den anderen relevanten Festlegungen der Richitlinie 1999/5/EG. (Wien) Nederlands Hierbij verklaart JVC KENWOOD dat het toestel KD-R951BT/KD-R852BT/KD-R851BT in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG. Bij deze verklaat JVC KENWOOD dat deze KD-R951BT/KD-R852BT/KD-R851BT voldoet aan de essentiële eisen en aan de overige relevante bepalingen van Richtlijn 1999/5/EC. Italiano Con la presente JVC KENWOOD dichiara che questo KD-R951BT/KD-R852BT/KD-R851BT è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Español Por medio de la presente JVC KENWOOD declara que el KD-R951BT/KD-R852BT/KD-R851BT cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Português JVC KENWOOD declara que este KD-R951BT/ KD-R852BT/KD-R851BT está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. Polska JVC KENWOOD niniejszym oświadcza, że KD-R951BT/KD-R852BT/KD-R851BT spełnia zasadnicze wymogi oraz inne istotne postanowienia dyrektywy 1999/5/EC. Český JVC KENWOOD tímto prohlašuje, že tento KD-R951BT/KD-R852BT/KD-R851BT je ve shodě se základními požadavky a dalšími příslušnýmiрΕ ustanoveními směrnice 1999/5/ES. Magyar Alulírott, JVC KENWOOD, kijelenti, hogy a jelen KD-R951BT/KD-R852BT/KD-R851BT megfelel az 1999/5/EC irányelvben meghatározott alapvető követelményeknek és egyéb vonatkozó előírásoknak. SvenskaHärmed intygar JVC KENWOOD att denna KD-R951BT/KD-R852BT/KD-R851BT stär l överensstämelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.Suomi JVC KENWOOD vakuuttaa täten että KD-R951BT/ KD-R852BT/KD-R851BT tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Slovensko S tem JVC KENWOOD izjavlja, da je ta KD-R951BT/ KD-R852BT/KD-R851BT v skladu z osnovnimi zahtevami in ostalimi ustreznimi predpisi Direktive 1999/5/EC. Slovensky Spoločnosрb JVC KENWOOD týmto vyhlasuje, že KD-R951BT/KD-R852BT/KD-R851BT spĺňa zákldné požiadavky a ďalšie prislušné ustanovenia Direktĺvy 1999/5/EC. Dansk Undertegnede JVC KENWOOD erklærer harved, at følgende udstyr KD-R951BT/KD-R852BT/ KD-R851BT overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. Ελληνι\bά рfΕ ΤΗΝ ΠΑΡΟΥΣΑ JVC KENWOOD ΔΗΛΩрΕΝΕΙ ΟΤΙ KD-R951BT/KD-R852BT/KD-R851BT ΣΥрfрfΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙрΕΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟрΕΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙрΕΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/EK. EestiSellega kinnitab JVC KENWOOD, et see KD-R951BT/ KD-R852BT/KD-R851BT vastab direktiivi 1999/5/EC põhilistele nõudmistele ja muudele asjakohastele määrustele. Latviešu Ar šo, JVC KENWOOD, apstiprina, ka KD-R951BT/ KD-R852BT/KD-R851BT atbilst Direktīvas 1999/5/EK galvenajām prasībām un citiem tās nosacījumiem. Lietuviškai Šiuo, JVC KENWOOD, pareiškia, kad šis KD-R951BT/ KD-R852BT/KD-R851BT atitinka pagrindinius Direktyvos 1999/5/EB reikalavimus ir kitas svarbias nuostatas. Malti Hawnhekk, JVC KENWOOD, jiddikjara li dan KD-R951BT/KD-R852BT/KD-R851BT jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC. Ук\fаїнська Компанія JVC KENWOOD заявляє, що цей виріб KD-R951BT/KD-R852BT/KD-R851BT відповідає ключовим вимогам та іншим повязаним положенням Директиви 1999/5/EC. Turkish Bu vesileyle JVC KENWOOD, KD-R951BT/ KD-R852BT/KD-R851BT ünitesinin, 1999/5/EC Direktifinin başlıca gereksinimleri ve diğer ilgili hükümleri ile uyumlu olduğunu beyan eder.
Page 4
3 BASICS To Do this (on the faceplate) Do this (on the remote control) Turn on the power Press B /SOURCE. - Press and hold to turn off the power. ( not available ) Adjust the volume Turn the volume knob. Press VOL + or VOL –. Press the volume knob to mute the sound or pause playback. - Press again to cancel. Press to mute the sound or pause playback. - Press again to cancel. Select a source - Press B /SOURCE repeatedly. - Press B /SOURCE, then turn the volume knob within 2 seconds. Press SOURCE repeatedly. Change the display information Press DISP repeatedly. ( 17) - Press and hold to scroll the current display information. ( not available ) Attach How to reset Detach Your preset adjustments will also be erased. Remote control (RM-RK52) (not supplied) KD-R951BT can be remotely controlled with an optionally purchased remote control. Faceplate KD-R951BT KD-R951BT Volume knob (turn/press) Loading slot Detach button Display window ENGLISH | How to replace the battery Pull out the insulation sheet when using for the first time. Remote sensor (Do not expose to bright sunlight.)
Page 10
9 ENGLISH | BLUETOOTH® Pair a Bluetooth device When connecting a Bluetooth device to the unit for the first time, perform pairing between the unit and the device. Once the pairing is completed, the Bluetooth device will remain registered in the unit even if you reset the unit. - Up to five devices can be registered (paired) in total. - A maximum of two Bluetooth phones and one Bluetooth audio device can be connected at any time. - This unit supports Secure Simple Pairing (SSP).- Some Bluetooth devices may not automatically connect to the unit after pairing. Connect the device to the unit manually. Refer to the instruction manual of the Bluetooth device for more information. 1 Press B /SOURCE to turn on the unit. 2 Search and select JVC UNIT on the Bluetooth device. BT PAIRING flashes on the display. - For some Bluetooth devices, you may need to enter the Personal Identification Number (PIN) code immediately after searching. 3 Perform (A) or (B) depending on what scrolls on the display. - For some Bluetooth devices, pairing sequence may vary from the steps described below. (A) [Device Name] XXXXXX VOL – YES BACK – NO - XXXXXX is a 6-digit passkey randomly generated during each pairing. You can operate Bluetooth devices using this unit. Connect the microphone If you turn off the unit or detach the control panel during a phone call conversation, the Bluetooth connection is disconnected. Continue the conversation using your mobile phone. Supported Bluetooth profiles– Hands-Free Profile (HFP1.5) – Advanced Audio Distribution Profile (A2DP) – Audio/Video Remote Control Profile (AVRCP1.3) – Object Push Profile (OPP) – Phonebook Access Profile (PBAP) – Serial Port Profile (SPP) Adjust the microphone angle Secure using cord clamps (not supplied) if necessary. Microphone input jack Microphone (supplied) Rear panel Ensure that the passkey which appears on the unit and Bluetooth device is the same. Press the volume knob to confirm the passkey. Operate the Bluetooth device to confirm the passkey. (B) [Device Name] VOL – YES BACK – NO Press the volume knob to start pairing. - If PAIRING PIN 0000 scrolls on the display, enter the PIN code 0000 into the Bluetooth device. You can change to a desired PIN code before pairing. ( 13) - If only PAIRING appears, operate the Bluetooth device to confirm pairing. PAIRING COMPLETED appears when pairing is completed. - or will light up when a Bluetooth mobile phone is connected. - will light up when a Bluetooth audio player is connected. Bluetooth compatibility check mode You can check the connectivity of the supported profile between the Bluetooth device and the unit. - Make sure there is no Bluetooth device connected. 1 Press and hold . BLUETOOTH CHECK MODE appears. SEARCH NOW USING PHONE PIN IS 0000 scrolls on the display.
