Jvc JR S401 Service Manual
This is the 42 pages manual for Jvc JR S401 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Jvc JR S401 Service Manual (Ocr-read)
Page 2
JR~S401
No. 2452
Contens
Page
1. Specifications ........................................................ 2
2. Level Diagram ........................................................ 2
3. Removal Procedures
3-(1) Top Cover and Bottom Plates ....................................... 3
3-l2) Front Panel and Window Screen ..................................... 4
3-(3) Pushbuttons .................................................. 5
3-(4) TAP-273B Power Amp. P.C. Board Ass'y ................................ 5
4. Main Parts Location .................................................... 6
5. Exploded Views and Part Numbers
5-(1) Front Panel . . . . .' .............................................. 7
5-(2) Rear Panel ................ - .................................... 8
5-(3) Replacement of the Power Transistor .................................. 8
6. Dial Stringing Procedures ................................................. 9
7. FM/AM Tuner Alignment Procedures
7-(1) PM Section ................................................... 1o
7-(2) AM Section . . . . . ; ............................................. 12
8. Power Amplifier Adjustment Procedures
8-(1) Center Voltage ................................................. 13
8-(2) Idling Current ................................................. 13
8-(3) Power Meter .................................................. 13
9. Printed Circuit Board Ass'y and Parts List
9-(1) TFC-238 FM/AM Tuners and Equalizer Amp. P.C. Board Ass'y ................ 14
9-(2) TXX-114A Select Switch P.C. Board Assy .............................. 22
9-(3) TXX-11SB Speaker Terminal P.C. Board Ass'y ........................... 23
9-(4) TXX-11GB Pin-jack P.C. Board Ass'y .................................. 24
9-(5) TXX-117E (or F and TXX-130E (or F) AC Block P.C. Board Ass'y ........... 25
9-(6) TPS-118C (or D) DC Power Supply P.C. Board Ass'y ....................... 26
9-0) TPS-126E, F, G (orH) Fuse P.C. Board Ass'y ............................. 28
9-(8) TAP-273B Power Amp. P.C. Board Ass'y ............................... 29
(HQ) TAG-4888 S.E.A. (Sound Effect Amp.) P.C. Board Assy ................... '. 34
10. Packing Materials and Part Numbers ...................................... , . . . 37
11. Accessories List ....................................................... 37
12. JR-S401 Schematic Diagram .............................................. 33
13. Parts List with Specified Numbers for Designated Areas ............................. 40
Warning!
When replacing the parts marked with A , be sure to use the designated parts to ensure safety.
