Jvc JA S8 Service Manual
This is the 23 pages manual for Jvc JA S8 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Jvc JA S8 Service Manual (Ocr-read)
Page 2
INDEX
PAGE
SPECIFICATIONS ................................................................ 2
LEVEL DIAGRAM ................................................................ 3
BLOCK DIAGRAM ................................................................ 4
FEATURES ...................................................................... 5
HOW TO CHECK THE .CENTER VOLTAGE AND THE IDLING CURRENT OF
POWER AMPLIFIER .............................................................. 6
FINAL PACKING ASSY ........................................................... 7
REMOVAL OF THE TOP COVER AND BOTTOM PLATE ............................... 7
MAIN PARTS LOCATION (TOP VIEW) .............................................. 8
LIST OF FRONT PANEL PARTS FOR REPLACEMENT ................................ 9
EXPLODED VIEW OF MECHANICAL PARTS (FRONT PANEL) .......................... 'IO_
EXPLODED VIEW OF MECHANICAL PARTS (REAR PANEL) ........................... 11
LIST OF REAR PANEL PARTS FOR REPLACEMENT ................................. 12
TSC-4B FUSE CIRCUIT BOARD ASSY .............................................. 12
TAG-2933 FILTER CIRCUIT BOARD ASSY (BOTTOM VIEW) .................. I ........ 13
TACv294 VOLUME RESISTOR CIRCUIT BOARD ASSY (BOTTOM VIEW) ................. I3
TPS-7 POWER SUPPLY CIRCUIT BOARD ASSY ................................ -. . . . 14
TAEv104C EQUALIZER CIRCUIT BOARD ASSY ...................................... 14
TAD-1598 POWER DRIVE CIRCUIT BOARD ASSY ................................ 15,16
TAC~295 PIN JACK CIRCUIT BOARD ASS'Y ......................................... 17
TAG-BOOB SOCKET CIRCUIT BOARD ASSY (BOTTOM VIEW) .......................... 17
SEA. CONTROL AMPLIFIER CIRCUIT BOARD ASS'Y (TOP VIEW) ..................... 18
SEA. CONTROL AMPLIFIER CIRCUIT BOARD ASSY (BOTTOM VIEW) ............ ..... 19
PARTS LIST WITH SPECIFIED NUMBERS FOR DESIGNATED AREAS ................... 20
LIST OF ACCESSORIES AND ATTACHMENTS ....................................... 20
COMPARISON TABLE FOR LINE VOLTAGE, POWER CONSUMPTION,
PRIMARY FUSE BY AREAS ....................................................... 2O
JA-SS No. 2353-1
