Extracted text from Jvc HAF 71 Service Manual (Ocr-read)
Page 1
HA-F51-E/K/N HA-F71-E/K/N HA-F91-E/K/N 1-2 (No.70285) Packing Method (HA-F51) Wiring Diagram (HA-F51) *Sheet *Blister Cover *Sub Sheet L R Note : These parts which was marked *(Blister cover / Sub sheet and Sheet) will not be able to supply as our service parts. 3.5mm dia. Stereo Miniplug Right Driver Unit Left Driver Unit
Page 2
HA-F51-E/K/N HA-F71-E/K/N HA-F91-E/K/N (No.70285)1-3 Packing Method (HA-F71) Packing Materials * Parts marked ( ) are safety parts. When replacing, be sure to use the specified one. Wiring Diagram (HA-F71) SYMBOL PARTS NO. PARTS NAME QTY DESCRIPTION 1 J34148-001 Case 1 *Sheet *Blister Cover *Sub Sheet L R Note : These parts which was marked *(Blister cover / Sub sheet and Sheet) will not be able to supply as our service parts. 1 3.5mm dia. Stereo Miniplug Right Driver Unit Left Driver Unit
