Jvc HA 35 Service Manual
This is the 2 pages manual for Jvc HA 35 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Jvc HA 35 Service Manual (Ocr-read)
Page 1
(No.70263) VICTOR COMPANY OF JAPAN, LIMITED COMMUNICATION NETWORK BUSINESS UNIT, 1644, SHIMOTSURUMA, YAMATO-SHI, KANAGAWA-KEN, 242-8514, JAPAN Printed in Japan 0201(V) J46231-001Ear Pad2 1 Item No. Parts No. Parts Name Description Q'ty Parts marked ( ) are safety parts. When replacing, be sure to use the specified one. Parts List HA-35(E),(K),(N) Right Driver Unit Left Driver Unit 3.5mm dia. Stereo Miniplug *Blister Cover *Sub Sheet 1 Ear pad *Sheet Note : These parts which was marked *(Blister cover/sub sheet and sheet ) will not be able to supply as our service parts Because the blister cover and rear sheet cover together of this package are adhered by glue. Packing Method Wiring Diagram
