Page 1
1-2 (No.MB658)
SPECIFICATION
EX-AK2DB
Designs and Specifications are subject to change without notice.General
Power source AC 230 V
~, 50 Hz
Power consumption 24 W (in operation)
0.9 W (on standby)
Mass 3.1kg
External dimensions ( W × H × D) 232 mm × 100 mm × 269 mm
DVD player
Playable discs/files DVD VIDEO, DVD AUDIO, DVD,VR, VCD, Super VCD, CD, CD-R/RW
(CD, VCD, MP3, WMA, WAV,JPEG, MPEG1, MPEG2 format),DVD-R/RW (video format)
Video output
Color system PAL
Horizontal resolution 500 lines
Audio output
Analog sound output Speakers × 2
Output power (IEC 268-3) 60 W (30 W + 30 W) at 4 C (1 kHz/10% THD)
Fitting impedance 4 Ω to 16Ω
Headphones 11 mW/32 Ω
Fitting impedance 16 Ω to 1 kΩ
Subwoofer 500 mVrms/10 kΩ
Digital sound output
Optical -21 dBm to -15 dBm
Audio input
Sound input AUX × 1
Level 1 250 mV/50 kΩ
Level 2 500 mV/50 kΩ
Tuner (Digital Audio Broadcasting)
Band III tuner Receiving Frequency: 5A (174.928) - 13F(239.200) MHz
L-Band tuner Receiving Frequency: LA (1452.960) - LW(1490.624) MHz
Speaker
Type 1-way bass-reflex type
Magnetically shielded type
Speaker 8cm cone × 1
Power handling capacity 30 W
Impedance 4Ω
Sound pressure level 81 dB/W zm
Dimension (W × H × D) 120 mm × 161 mm × 239 mm
Mass (1 unit) 1.7 kg
Page 2
(No.MB658)1-3
SECTION 1
PRECAUTION
1.1 Safety Precautions
! Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
! Please use enough caution not to see the beam directly or touch it in case of an
adjustment or operation check.
