SPECIFICATION

I DR-DXSSEK I DR-DXSSEL/EU/EY/EZ
GENERAL
Power requirementl AC 220 V ~ 240 V, 50 Hz/60 HZ
Power consumption
Power on 45 W
Power off 15 W
Temperature
Operating 5°C to 35°C
Storage -20°C to 60°C
Operating position Horizontal only
Dimensions (W X H X D) 435 mm X 96 mm X 383 mm
Weight 6.5 kg
Input/Output
Video input 0.5 - 2.0 Vp-p, 75 £2 (pin jack)
Audio input -8 dB, 50 k9 (pin jack), Corresponding to mono (left)
Audio output -8 dB, 1 k0 (pin jack)
21-pin SCART connectors IN/OUT X 1, IN/DECODER X1
S-video input Y: 0.8 - 1.2 Vp-p, 75 £2, C: 0.2 - 0.4 Vp-p, 75 Q
S-video output Y: 1.0 Vp-p, 75 Q, C: 0.3 Vp-p, 75 0
DV 4-pin for DV IN/OUT
Component video output Y: 1.0 Vp-p, 75 £2, CB/CR, PB/PR: 0.7 Vp-p, 75 9
Corresponding to copy protection
Digital audio output Optical, Coaxial

Corresponding to Dolby Digital and DTS Digital Surround
Bit stream Selectable in digital audio output setting menu

VIDEO/AUDIO (DVD Deck)

Recording time Maximum 8 hours (with 4.7 GB disc)
(XP): Approx. 1 hour, (SP): Approx. 2 hours, (LP): Approx. 4 hours
(EP): Approx. 6 hours, (FR): Approx. 1 hour - 8 hours

Audio recording system Dolby Digital (2 ch), Linear PCM (XP mode only)
Video recording compression system MPEG2 (CBR/VBR)
VIDEO/AUDIO (HDD Deck)
Video recording compression system MPEG2 (VBR)
Audio recording system Dolby Digital (2 ch), Linear PCM (XP mode only)
Recording time Maximum 473 hours (with 250 GB HDD)

(XP): Approx. 53 hours, (SP): Approx. 109 hours, (LP): Approx. 218 hours
(EP): Approx. 328 hours, (FR): Approx. 473 hours

VIDEO/AUDIO (DV Deck)

Signal system PAL colour signal, 625 lines/50 fields
Recording system Digital Component Recording
Format DV format (SD mode)
Cassette Mini DV Cassette
Maximum recording time
(SP) (SP): 80 min. with M-DV80ME cassette
(LP) (LP): 120 min. with M-DVBOME cassette
Audio recording system PCM 48 kHz, 16 bit (2 ch)/32 kHz, 12 bit (4 ch)
TUNERITIMER
Tuning system Frequency synthesized tuner
Channel coverage VHF : 44.5 MHZ - 143 MHZ/143 MHZ - 470 MHZ VHF : 47 MHZ- 89 MHZ/104 MHZ- 300 MHZ/302 MHZ-470 MHZ
UHF:470 MHZ-862 MHZ UHF:470 MHZ-862 MHZ
Memory backup time Approx. 60 minutes
ACCESSORIES

RF cable, 21-pin SCART cable,

Provtded accessories Infrared remote control unit, "AA/R6" battery x 2

- Specifications shown are for SP mode unless otherwise specified.

E.& O.E. Design and specifications subject to change without notice.

Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.

"DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems, Inc.

SHOWVIEW is a trademark of Gemstar Development Corporation. The SHOWVIEW system is manufactured under licence from Gemstar Devel-

opment Corporation.(EL, EU, EY, EZ MODEL)

- VIDEO Plus+ and PlusCode are registered trademarks of Gemstar Development Corporation. The VIDEO Plus+ system is manufactured under
license from Gemstar Development Corporation.(EK MODEL)

- i(i.Link) refers to the IEEE1394-1995 industry specification and extensions thereof. Thei logo is used for products compliant with the i.Link stan-
dard.

1-2 (N0.YD085)
