Jvc 5944 Owners Manual

Page 2

CAUTIONS

1. If the earpads do not fit your ears tightly air leakage will result
and cause low frequency sounds to deteriorate.

2. Don't connect them directly to an amplifier whose output is
over lOOmW, or the delicate voice coils will be damaged. Be
sure connect a resistance of 100 to 300 ohms in series to. lower
the output power. This will not lessen the tone quality.

3. Clean the earpads, headband and earcups with a piece of soft
cloth and neutral cleaner.

CONSTR UCTION

As shown in the figure, the length of the slide band can be varied
depending on the size of your head. The position of the earcups
can also be adjusted. Try to make it suit you as well as you
can. The earpads are made of soft artificial leather and
cushioning gives you comfortable monitoring.

PHASE SHIFTER SWITCH

Normally set this switch to NORM (in-phase). For some discrete
or matrix sources the reproduced sound can be improved with the
switch set to REVERSE (anti-phase). By changing the position
of this switch you can make the sound from the headphones as
real as sound in a concert hall. When you are listening to a
2channel source from a single jack use the optional TWC-l twin
cord connector to improve the performance of your headphones.

Headband

Adjusting screw Slide band
/ \ O .
Loosen O Tighten ': Adjustable

MS a e
Phase Shifter Name plate \
WT V0..\

PHAS
Parallel cords (2m)

NORM

El

REV

v
5944 '

CH-1/CH-3
indication tag

CH-2/CH-4

Common earth for . . .
Indication tag

CH-1 and CH-3

Common earth for
CH-2 and CH4

CH-llL) CH3?! 0.44le
\.-v-
FRONT CH-ZlL }REAR
