Jbl scs 200 service manual
This is the 25 pages manual for jbl scs 200 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from jbl scs 200 service manual (Ocr-read)
Page 1
Advanced Product Information PRO SOUND COMES HOME!™ JBL Consumer Products, Harman Consumer International, 2, Route de Tours, 72500 Château du Loir, France. Tel: + 33 (0)2 43 38 43 00, Fax: + 33 (0)2 43 44 93 83 www.jbl.com Provisional Specifications SCS 260 Satellite Frequency Response: 100Hz – 20kHz Sensitivity( 2.83V@1m): 88dB Nominal Impedance: 8 Ohm Maximum Recommended Amplifier Power1 : 100 Watt RMS Power Handling (Continuous/Peak): 50W/200W High Frequency Driver: ½ (13mm) Titanium laminate dome with JBL EOS™ waveguide Low Frequency Driver: Dual 3 (75mm) PolyPlas™ Magnetic Shielding: Yes Dimensions*: 11½ x 4 x 3½ 292mm x 101mm x 89mm Weight per Speaker: 1.36kg (3 lb) *excludes shelf stand SCS 260 Center Frequency Response: 100Hz – 20kHz Sensitivity( 2.83V@1m): 88dB Nominal Impedance: 8 Ohm Maximum Recommended Amplifier Power1 : 100 Watt RMS Power Handling (Continuous/Peak): 50W/200W High Frequency Driver: ½ (13mm) Titanium laminate dome with JBL EOS™ waveguide Low Frequency Driver: Dual 3 (75mm) PolyPlas™ Magnetic Shielding: Yes Dimensions*: 4 x 11½ x 3½ 101mm x 292mm x 89mm Weight per Speaker: 1.36kg (3 lb) *excludes shelf stand SCS 260 Subwoofer Low Frequency Cut-off: 35Hz High Frequency Cut-off: 160Hz Built-in Power Amplifier: 100 Watt RMS Inputs: Line Level: LFE + Left and Right RCA Phono Inputs: High Level: Left and Right speaker terminals Outputs High Level: Left and Right speaker terminals Auto-on Mode: Yes Driver: 8 (200mm) Long Throw Cellulose Fiber Port: FreeFlow™ flared Magnetic Shielding: No Dimensions*: 16¼ x 11 x 13¾ 413mm x 280mm x 349mm Weight per Speaker: 12.7kg (28 lb) *including feet
Page 2
Advanced Product Informat ion PRO SOUND COMES HOME!™ JBL Consumer Products, Harman Consumer International , 2, Route de Tours, 72500 Château du Loir, France. Tel: + 33 (0)2 43 38 43 00, Fax: + 33 (0)2 43 44 93 83 www.jbl.com Provisional Specifications SCS 200 Satellite Frequency Response: 110Hz – 20kHz Sensitivity( 2.83V@1m): 86dB Nominal Impedance: 8 Ohm Maximum Recommended Amplifier Po wer1 : 75 Watt RMS Power Handling (Continuous/Peak): 40W/160W High Frequency Driver: ½ (13mm) Titanium laminate dome with JBL EOS ™ waveguide Low Frequency Driver: 3 (75mm) PolyPlas™ Magnetic Shielding: Yes Dimensions*: 7¼ x 4 3½ 184 mm x 10 1mm x 89mm Weight per Speaker: 0.7 9kg (1.7 5 lb) * excludes shelf stand SCS 200 Center Frequency Response: 100Hz – 20kHz Sensitivity( 2.83V@1m): 88dB Nominal Impedance: 8 Ohm Maximum Recommended Amplifier Power 1 : 100 Watt RMS Power Handling (Continuous/Peak): 50W/200W High Frequency Driver: ½ (13mm) Titanium laminate dome with JBL EOS™ waveguide Low Frequency Driver: Dual 3 (75mm) PolyPlas™ Magnetic Shielding: Yes Dimensions*: 4 x 11½ x 3½ 101 mm x 2 92mm x 89mm Weight per Speaker: 1.36 kg ( 3 lb) * excludes shelf stand SCS 200 Subwoofer Low Frequency Cut -off: 35Hz High Frequency Cu t-off: 160Hz Built -in Power Amplifier: 100 Watt RMS Inputs: Line Level: LFE + Left and Right RCA Phono Inputs: High Level: Left and Right speaker terminals Outputs High Level: Left and Right speaker terminals Auto -on Mode: Yes Driver: 8 (200mm ) Long Throw Cellulose Fiber Port: FreeFlow™ flared Magnetic Shielding: No Dimensions*: 16¼ x 11 x 13¾ 41 3mm x 280mm x 3 49mm Weight per Speaker: 12.7 kg (28 lb) *including feet
