Jbl scs 135 service manual
This is the 20 pages manual for jbl scs 135 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from jbl scs 135 service manual (Ocr-read)
Page 1
SCS135 2 TABLE OF CONTENTS BASIC SYSTEM SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 DETAILED SUB135 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 MECHANICAL/PACKAGING PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 SUB135 DETAILED EXPLODED VIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 TEST SET UP AND PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 PACKAGING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 ELECTRICAL PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 INTEGRATED CIRCUIT DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 PRINTED CIRCUIT BOARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 SCHEMATICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Page 2
SCS135 3 Specifications SCS135 SYSTEM Frequency Response35Hz - 20kHz (-6dB) Satellites Recommended Power 10 - 100 watts Impedance 8 ohms nominal Sensitivity 86dB @ 1 watt/1 meter Tweeter One 1/2" titanium-laminate dome, video-shielded Midrange One 3" driver, video-shielded Dimensions (H x W x D) 4-3/8" x 3-3/16" x 3-3/4" 111mm x 81mm x 95mm Weight 1.1lb/0.5kg Center Channel Recommended Power10 - 50 watts Impedance 8 ohms nominal Sensitivity 86dB @ 1 watt/1 meter Tweeter One 1/2" titanium-laminate dome, video-shielded Midrange Dual 3" drivers, video-shielded Dimensions (H x W x D) 3-1/4" x 7-5/8" x 3-3/4" 83mm x 194mm x 95mm Weight 1.89 lb/0.86kg SUB135 Subwoofer 100 watts RMS 8" woofer, bass-reflex enclosure Dimensions (H x W x D) 15" x 13" x 14" 381mm x 330mm x 356mm Weight 30 lb/13.6kg Refinements may be made on occasion to existing products without notice, but will always meet or exceed original specifications unless otherwise stated. Simply Cinema is a registered trademark of JBL, Incorporated.
