L.F. + – U.H.F. H.F. /U.H.F.INPUT L.F. INPUT + – H.F. .205 .110 –IN +IN –IN +IN R1 150ohm 5W R5A 60ohm 5W RED ORN ORN/BLK BLK R5B 60ohm 5W R6A 60ohm 5W R6B 60ohm 5W R8 9.1ohm 5W R9 6.8ohm 5W R10 12ohm 5W R1 33ohm 5W R1 1.5ohm 1W R7 1.8ohm 5W R2 33ohm 5WR3 130ohm 1WR4 62ohm 1W BI-AMP S1C BI-AMP S4A HF LEVEL 2 1 3 NORMAL C3C C3A C3B C3A C4A C2A C1A C3B C4B C2B C1B C5B C5A C6B C6A C7B C7A C8B C8A C9B C9A C10B C10A C11B C11A C12B C12A YEL YEL/BLK C1A C2A C1B C2B 9V 9V 9V 9V 9V R102 2.2Mohm 1/4W R103 2.2Mohm 1/4W 9V R104 2.2Mohm 1/4W 9V R105 2.2Mohm 1/4W 9V R106 2.2Mohm 1/4W R101 2.2Mohm 1/4W R101 2.2Mohm 1/4W R102 2.2Mohm 1/4W L2 .2mH L6 .6mH L1 .25mH L1 .03mH L2 .15mH L4 1.0mH L3 2.0mH L5 1.0mH R101 2.2Mohm 1/4W 9V HM L S2 LF DAMPING L1 4.5mH NORMAL NORMAL BI-AMP S1A, B BI-AMP RED GRN GRN/BLK BLK BI-AMP L2 1.0mH R2 100ohm 5W R3 51ohm 10W CAPACITOR LEGEND U.H.F. C1A, C2A: 3.0 µF, 100V C3A, C4A: 4.0 µF, 100V C1B, C2B, C3B, C4B: 0.01 µF H.F.C1A, C2A: 24 µF, 100V C3A, C4A: 47 µF, 100V C3B, C4B: 1 µF, 100VC5A, C6A: 12 µF, 100V C7A, C8A: 24 µF, 100V C9A, C10A: 14 µF, 100V C11A, C12A: 2 µF, 100V C1B, C2B, C3C, C4C, C5B, C6B, C7B, C8B, C9B, C10B, C11B, C12B: 0.01 µF L.F.C1A, C2A: 82 µF, 100VC1B, C2B: 4 µF, 100VC1C, C2C: 0.01 µF C4C C4A C4B C1C C1A C1B C2C C2A C2B RED BLK T echnical Manual K2 S9800 JBL Consumer Products, 250 Crossways Park Drive, Woodbury, New York 11797 2R ev 1 2/2002 K2 S9800 SCHEMATIC
Page 2
36 41 28 22 16 2 11 32 21 3 7 29 34 14 13 12 25 39 35 8 33 10 26 19 6 40 9 38 31 20 23 17 5 4 18 35 37 1 30 35 24 15 27 Technical Manual K2 S9800 JBL Consumer Products, 250 Crossways Park Drive, Woodbury, New York 11797 3Rev 0 1/2002 K2 S9800 EXPLODED VIEW TO SERVICE THE K2 S9800The crossover network, after removal of the (6) faceplate screws, should extract far enough out of the cabinet for service without wire or driver removal. Access to 9V bias batteries – metal plate removed by two thumbscrews on the network faceplate. Replacement or service of the high-frequency drivers requires access through the woofer opening, following these steps: NOTE: IT IS RECOMMENDED TWO PERSONS BE INVOLVED IN K2S9800 DISASSEMBLY 1) Lay the loudspeaker down, on its back (drivers facing up), on a padded surface. 2) Remove the grille. 3) Remove the (8) Phillips woofer screws. 4) The woofer is best extracted by inserting two 1/4 x 20 (3" or longer) threaded machine screws into opposite sides of the two threaded woofer screw openings. Caution: Only two of the holes are threaded; they should be the top and bottom holes in the woofer frame. Threadthe bolts into the openings by hand, then pull upwards, lifting the woofer from the counterbore. Then, while one person supports the woofer, another can remove both connecting wires from the terminals. Set the woofer aside. 5) Inside the cabinet, at the bottom of the HF horn, are the three mounting screws; remove them. 6) The HF horn can now be removed from the cabinet by reaching in and pushing the assembly out; remove both connecting wires from the terminals. Set the HF assembly/horn aside. 7) The (10) screws holding the top cap assembly are now exposed; remove them. 8) Lift the top cap assembly with UHF assembly off the cabinet. NOTE: a) When replacing the HF horn, to assist the (3) screw holes in lining up properly, one person may have to depress the gasket by pressing the horn assembly down into the cabinet, while the other replaces the screws. b) Remember to observe correct polarity when reattaching all driver wires.
