Jbl htps 400 service manual
This is the 32 pages manual for jbl htps 400 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from jbl htps 400 service manual (Ocr-read)
Page 1
HTPS-400 CONTENTS SPECIFICATIONS …….……………….…………….………………….3 DETAILED SPECIFICATIONS ……………………..…………………4 CONNECTIONS ………………………………………………..………6 OPERATION……………………………………..……..…..…….……..8 TROUBLESHOOTING…….…….………………….………………….9 AMPLIFIER BLOCK DIAGRAM…………..…………….……………10 PACKAGING …………………………….………………………….…11 EXPLODED VIEW ……………………………………….……………12 EXPLODED VIEW OF AMPLIFIER…………………….……………13 TEST SETUP and PROCEDURE……………….……..……………14 HTPS-400 ADJUST BIAS PROCEDURE… ….… ……… ..…… ……… 15 ELECTRICAL PARTS LIST (120v)……………….…….….…………16 INTEGRATED CIRCUIT DIAGRAMS ………………………………23 PRINTED CIRCUIT BOARD DIAGRAMS………………..…………24 SCHEMATICS……………….…..……….……………………………28
Page 2
HTPS-400 SUBWOOFER 3 Specifications Frequency Response: 28Hz - 200Hz Input:THX® and normal line level Output:Line level (loop through from input) Sensitivity:91dB Maximum Amplifier Output:1000 watts Driver:12" with aluminum cone and rubber surround, video-shielded Crossover Frequency:50Hz - 150Hz (continuously adjustable) Dimensions (H x W x D):14-5/8" x 14-5/8" x 14-5/8 (371mm x 371mm x 371mm) Weight:62 lb (28kg) THX is a registered trademark of Lucasfilm, Ltd.
