2142

300 mm (12in)
Coaxial Transducer

Professional Series

Key Features:

D New 44 mm (1175 in) Pure Titanium
Dome High Frequency Transducer
Frequency Range (, 10 dB):
()0 Hz , 22 kHz
Sensitivity: 97 dB SPL 1 W',
1 m (3.3 ft)

D Power Capacity: 90 \V IEC
Pink Noise

BirAmplifier Terminals

>Integral Transformer Mounting
Bracket

The JBL 2142H Coaxial Transducer
represents the results of JBLs intenr
sive research into the performance
and applications of coaxial transr
ducers intended for engineered
sound applications. To achieve maxir
mum power handling while main
taining wide bandwidth and consis
tent dispersion in several critical HF
octave bands, JBL engineers develr
oped a new size and configuration
44 mm (1175 in) highrfrequency trans
ducer, incorporating a pure titanium
dome with JBLs patented diamond
surround for control over secondary
resonances.

The low frequency driver combines
a rugged diercast frame with a spe
cially designed cone and 51 mm (2 in)
Voicercoil motor structure that oper
rates in tandem with the HF element
to sustain smooth system response
and stable dispersion through the
crossover regionr

An integral transformer mounting
bracket, builtrin provisions for quick
biramplifier hookups, and a special
snaproff network access cover are all
designed to reduce contractor fabricar
tion time in the shop and installer
placement time at the site

In response to consultant and cone
tractor requests, the JBL 2142H was
designed to perform well in the most
commonlyrspecified utility metal
enclosure and baffle combinations,
despite the generally detrimental
acoustical properties of those enclor
suresr Customrbuild boxes will usually
result in better performance characr
teristics than those published here

Preliminary Specifications:

SYSTEM:

Frequency Range ( . 10 dB):

60 Hz , 22 kHz

Power Raung:

90 \X' continuous pink noise

Sensitivity :

97 dB, 1 w (2.83 w, 1 m (3.3 ft)

Nominal Impedance:

8 ohms

Crossover Frequency:

2.7 kHz

LOW FREQUENCY TRANSDUCER:

Nominal Diameter:

300 mm (12 in)

Voice Coil Diameter:
Magnet \V'cighr:

51 mm (2 in)
1.1 kg (2.4 lb)

Sensitivity ':

93 dB, 1 \x (2.83 w, 1 m (3.3 ft)

HIGH FREQUENCY DOME RADIATOR:

Nominal Diameter:
Voice Coil Diameter:

50 mm (1.95 in)
44 mm (1.75 m)

Magnet \xergnr:

Sensitivity"

0.54 kg (1.2 lb)
98 dB, 1 \x (2.83 w, 1 m (3.3 ft)

Dispersion An 1e: 80° Nominal
GENERAL:
Polarity: Positive voltage to ( + ) terminal on network

Input l'erminauons:

Transformer Mountin :

Recommended Enclosure Volume:

input gives forward L.F. cone motion

2 x 2 barrier strip with removable ,nmpers to
permit biramplification

Intc ral mountin plate on LP frame
3 cu ft

System Net Weight:

5.5 kg (12 lb)

(1, Rn:

r hm: on no om: or mnren random non-r Lontormlng

me

nnutmnl vandard 11.1: 2684 (pmk "qu wh

12 dB ptr ornne ronor belt) 40 III and more 31101» Hz \urh n pea rmrmLmgL mno or a any, 2 1mm duration

from sun H, to 2% u],

( \\u m (mm mi 112 to sun 11,
(4) Averaged mm 2 kHz tn 10 kHz

(5) lntluded by 76 dB dawn paints, averaged between 1 kHz and 10 kHz
