Interm qd 4960 quad amp
This is the 10 pages manual for interm qd 4960 quad amp.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from interm qd 4960 quad amp (Ocr-read)
Page 2
ELECTWCALADJUSTMENTPROCEDURE
I IDLE CURRENT
A. Setting
Set the master volume minimum.
B. Connection
O
TP1 TP2
R237 R236 0
R342 R343
® _W,_ _w,_ @ VOLT METER
VR201 VR301
AMP BD
C. Adjustment
-Adjust VR301 so that the current through the R237, R236, R342, R343 become 10 milliampere.
-When that voltage across the TP1 to TP2 becomes 10 millivolt, the current becomes 10
milliampere.
CONTENTS
Electrical Adjustment Procedure 1
Specifications . . . . . . . . . . . . . . . . . . . . . . 2
Electrical Parts List -------------------- 3
Top and Bottom View of RC. Board - - - - - - - - - - - - -5.
Wiring Diagram ...................... 7
Block Diagram . . . . . . . . . . . . . . . . . . . 8
Schematic Diagram .................... 9 1o! 11, 12
Exploded View of Cabinet & Chassis / Mechanical Parts List . . 13, 14
Assy Drawing ...................... 151 16
