ELECTRICAL PARTS LISI' ( PAM-TUlER )

Ref No. Part No. DescriptIon VaIue Qty
TUhER B'D
A/PACK 3928009980 AM TUNERIFAM17210V) D [I D [I AM TUNER PACK 1
C419 35091025301 CAP CE B 0.001UF 50V] 0. 001/ 50 1
C421 C423 35091035301 CAP CE F 0.01UF 50V Z 0.01/50 2
C401 C403 C405 35092235301 CAP CE F 0.022UF 50V Z 0. 022/ 50 6
C417A418 C428
C400 C402 35094735301 CAP CE F 0.047UF 50V Z 0. 047/ 50 2
C411 35091045301 CAP CE F 0.1UF 50V Z 0.1/ 50 1
C425 35291001101 CAP CE RH 10PF 50V D 10P 1
C409 C424 35293302101 CAP CE CH 33PF 50V] 33P 2
CF4007401 3908011001 FILTER SK107M37A0720 TOKO 10.7M 2
L3 2648399930 COIL PEAKING 0.33UH(PA»600RB) 0.33 1
L 2648699980 COIL CHOCK COMMON MODE PA7608R CHOCK 1
CON4017402 4428598304 WAFER LW-064074P LW7064074P 2
CON403 4428598303 CONNECTOR WAFER LW7064073P LW7064073P 1
CON400 4428598305 CONNECTOR WAFER LW70640A5P LW»064075P 1
CON404 4355898203 CON ASS'Y 26P ASS'Y 26P 1
D401»405 [3407409 2058304100 DIODE |N4148M 1N4148 22
D411 [3413425
C414 3419510401 CAP AF 0.1UF 5.5V(EECF5R5U104I 0.1/ 5.5 1
C420 34092228711 CAP AF RSG 0.22UF 50V 5 P 0.22/ 50 1
C413 34092478711 CAP AF RSG 0.47UF 50V 5 P 0.47/50 1
C404 C406 C416 C430 34092109711 CAP AF RSG 1UF 50V 5 P 1/50 4
C410 34092479711 CAP AF RSG 4. 7UF 50V 5 P 4. 7/ 50 1
C407 C412 C422 C426 34092470711 CAP AF RSG 47UF 50V 6 P 47/ 50 4
C408 36392741111 CAP ECQ-V 1H274J L2 0.27UF 50V 027/ 50 1
F/ E 3928009990 TUNER PACK (AM) TUNER PACK(AM) 1
0411 20182111001 FET N»CH 25K 1680 SANKYOELE 2SK 168D 1
L4 2628099940 COIL FM DET FM DET 1
IC400 2138013995 IC UPD171967014 12 D171967014 1
IC401 2168417994 IC LA 1145(FM IF) SANYO LA1195/1145IFM-IFI 1
C429 36096821201 CAP MA 0.0068UF 100V] 0. 0068/ 100(M) 1
C431 36092231201 CAP MA 0.022UF 100V] 0. 022/ 100(M) 1
C427 36093331201 CAP MA 0.033UF 100V] 0.033/100IM) 1
C415 36094731201 CAP MA 0.047UF 100V 0. 047/ 100(M) 1
R451 3009152973 RES CF 15K 1/ 5W1 N 1.5K 1
R404 R446 R459 3009101973 RES CF 100 1/ SW] N 100 3
R421 3039101572»F RES MO 100 2WJ N 100 2W 1
R402 R440 R443 3009104973 RES CF 100K 1/ 5W1 N 100K 3
R426 3009100973 RES CF 10 1/ SW] N 10 1
R410 R415 R417 3009103973 RES CF 10K 1/ SW] N 10K 14
R419-420 R428»429
R436r437 R441 R450
R452 R454-455
R412 3009123973 RES CF 12K 1/ SW] N 12K 1
R448 3009151973 RES CF 150 1/ SW] N 150 1
R424 3009154973 RES CF 150K 1/ SW] N 150K 1
R425 3009153973 RES CF 15K 1/ SW] N 15K 1
R413 3009183973 RES CF 18K 1/ SW] N 18K 1
R438 R447 R449 R464 3009102973 RES CF 1K 1/ SW] N 1K 4
R423 R431 R458 3009222973 RES CF 2.2K 1/ SW] N 2.2K 3
R435 3009272973 RES CF 2.7K 1/ 5W1 N 2.7K 1
R403 3009271973 RES CF 270 1/ SW] N 270 1
