Integra rfr 6 owners manual
This is the 12 pages manual for integra rfr 6 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from integra rfr 6 owners manual (Ocr-read)
Page 1
2 Care From time to time you should wipe the unit with a soft cloth. For heavier dirt, dampen a soft cloth in a weak solution of mild detergent and water, wring it out dry, and wipe off the dirt. Following this, dry immediately with a clean cloth. Do not use rough material, thinners, alcohol or other chemical solvents or cloths since these could damage the finish. FCC Information for User CAUTION:The user changes or modifications not ex- pressly approved by the party responsible for compliance could void the users authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital de- vice, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment gener- ates, uses and can radiate radio frequency en- ergy and, if not installed and used in accordance with the instructions, may cause harmful inter- ference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equip- ment does cause harmful interference to radio or television reception, which can be deter- mined by turning the equipment off and on, the user is encouraged to try to correct the interfer- ence by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equip- ment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the re- ceiver is connected. -Consult the dealer or an experienced radio/ TV technician for help. NOTE: If serial or parallel ports are configured, a fil- tered/shielded serial or parallel cable is recom- mended to minimize EMI and ensure FCC B compliance. Precautions This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any inter- ference received, including interference that may cause undesired operation. Changes or modifications not expressly ap- proved by the party responsible for compliance void the users authority to operate the equip- ment. For Canadian models NOTE: THIS CLASS B DIGITAL APPA- RATUS COMPLIES WITH CANADIAN ICES-003. For models having a power cord with a polar- ized plug: Modèle pour les Canadien REMARQUE: CET APPAREIL NUMÉRIQUE DE LA CLASSE B EST CON- FORME À LA NORME NMB-003 DU CANADA.
Page 2
3 Introduction About the RFR-6 Most remote controller systems have to be oper- ated by pointing the remote controller directly towards a device. Any obstacle between the re- mote controller and the device disturbs the oper- ating signal. But what if you like to place your devices inside a closed cabinet, a closet or even in another room? The RFR-6 provides the solu- tion to overcome obstacles like furniture or walls. Your devices no longer have to be placed in line of sight but can be operated from virtu- ally any location. The RFR-6 is a RF Receiver that is used in combination with the RF Remote Controller. The RF Receiver receives radio fre- quency (RF) signals sent out by the RF Remote Controller and converts them into infrared (IR) signals. These IR signals are then sent out to your TV, DVD, preamplifier and so on. - -/- --AB CD EF P Q RSTU V W X YZDirect TuningG HI JKLM NO Cap s D ele teLanguageLoca t ionA l bum Ar tis tGe n re Pla yli st @ .-'/ CustomDisplay DimmerT V/ V i d e oSleep RandomS t e p / S l o wMutingAn gle Su btit le A udio M em o ry S ear c h A- B R ep eat On Standby T V T V CH T V VOL RC- 55 0MR e c L a s t M e m o r y+ 100Clear12 3 4 56 7 8 9I n p u tZ o n e 2Inpu t M odeM a c r oVOL CHD i s cT e s t T o n eCH SEL Pure AS u r r o u n dDirectStereoR e- E QT HXAll CH STLevel +Level -L N i g h tAudio SELDSP DSPEnterAudioADJGuideMenuTopMenuSetupReturnExit RF signals IR signals RF Remote ControllerRF Receiver --/---ABC DEF PQRS TUVWXYZD i r e c t T u n i n gGHIJKL MNOCapsDeleteLanguage Loca t ionAlbumAr tist Genre Playlist @.-'/CustomDisplay DimmerT V/ V i d e oSleep RandomStep / SlowMutingAngle Subtitle Audio Memory Search A- B RepeatOnStandby T V T V CH T V VOLRC- 550MRec Last Memory+ 10 0Clear12 3 4 56 789I n p u tZ o n e 2Input ModeM a c r oVOL CHDiscT e s t T o n eC H S E L P u r e AS u r r o u n dD i r e c tS t e r e oR e- E QTHXAll CH S TL e v e l +L e v e l -L N i g h tAudio SELD S PD S PEnterAudioADJGuideMenuTopMenuSetupReturnExit Applications The RF Receiver can be used in several situations: ■Your devices can be remotely controlled while the RF Receiver is placed in line of sight (situation A). ■The RF Receiver controls devices placed in an adjacent room (situation B). ■The RF Receiver is placed inside a closet, a rack, etc. together with your devices (situa- tion C). ■The set-ups in situation A, B and C can be combined. If you want to control devices in different locations, you have to place a RF Receiver in each location. You can control all RF Receiver with the same RF Remote Controller. See Multiple RF Receiver on p. 8 to apply the necessary settings. Situation B Situation C Situation A
