Integra key 2 7 owners manual
This is the 20 pages manual for integra key 2 7 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from integra key 2 7 owners manual (Ocr-read)
Page 1
2 Precautions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Never expose the unit to moisture. 7. Suitable only for use Indoors. 8. Only connect specified supply volt- ages. 9. Connect only to the specified termi- nals. For U.S. models FCC information for User CAUTION: The user changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful inter- ference in a residential installation. For Canadian Models NOTE: THIS CLASS B DIGITAL APPARA- TUS COMPLIES WITH CANADIAN ICES- 003. Modèle pour les Canadien REMARGUE: CET APPAPEIL NUMÉRIQUE DE LA CLASSE B EST CONFORME À LA NORME NMB-003 DU CANADA.
Page 2
3 Table of Contents Precautions ..................................... 2 Introduction ...................................... 3 Features .......................................... 4 Part Names and Function ................ 5 Installation ....................................... 8 System Wiring ................................. 9 Manual Programming .................... 11 Troubleshooting ............................. 14 Specifications ................................ 14 Thank you for purchasing an Integra KEY-2.7 keypad. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance from your new keypad. Please retain this manual for future reference. Introduction The Integra KEY-2.7 keypad simply controls and provides status feedback of source selec- tion, power, mute and volume of an Integra MZA-4.7 multi-zone amplifier. The Keypad is programmed manually when connected to the amplifier.
