Integra dbs 50 2 service manual

Page 1

BBS-50.2

Ref. No. 4247

Integr a SERVICE MANUAL Sepmmo

BLU-RAY DISC PLAYER
MODEL DBS-50.2(B)CDD1 N

9 II] DOLBY

mum: WK. HD'T BlllflKBllS'IEII'

E/uraynlsmr
DIGITAL PLUS

AVCHD W BEDVEW fiagaoNus wgwmg dlna'1-H X.

CERTIFIED

x.v.Color DCIReDrufiaNow- WETHW .v' V (:9
1? m WE EEEE @flmfl ngg

lnleqla

Black model

B CDDlN 120V AC, 60Hz

RC-794DV

SAFETY-RELATED COMPONENT
WA R N I N G ! !

COMPONENTS IDENTIFIED BY MARK A ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.

MAKE LEAKAGE-CURRENT 0R RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.

Page 2

TABLE OF CONTENTS

Specifications .......................................................................... 1-1-1
Laser Beam Safety Precautions ............................................................ 1-2-1
Important Safety Precautions .............................................................. 1-3-1
Standard Notes for Servicing .............................................................. 1-4-1
Cabinet Disassembly Instructions ........................................................... 1-5-1
How to Initialize the BLU-RAY Disc Player .................................................... 1-6-1
Firmware Renewal Mode ................................................................. 1-7-1
Home Network (DLNA) Error Code .......................................................... 1-8-1
Block Diagrams ......................................................................... 1-9-1
Schematic Diagrams / CBA and Test Points .................................................. 1-10-1
Exploded Views ........................................................................ 1-11-1
Mechanical Parts List ................................................................... 1-12-1
Electrical Parts List ..................................................................... 1-13-1

Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
