Infinity l mps ownersmanual
This is the 8 pages manual for infinity l mps ownersmanual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from infinity l mps ownersmanual (Ocr-read)
Page 1
2 UNPACKING 1. Carefully unpack the speakers. If you suspect damage from transit, report it immediately to your dealer and/or delivery service. Keep the shipping carton and packing materials for future use.2. Verify that the package includes the following items: Ð (4) Minuette L- MPS Speakers Ð (1) Minuette Center-Channel Speaker Ð (4) Mounting Brackets (for L-MPS Speakers) Ð (4) Satellite Bases (for L-MPS Speakers) Ð (1) OwnerÕs Manual PLANNING YOUR SYSTEM The Infinity Minuette L-MPS Theater Pac consists of specific components for your home entertainment system. It is a five- piece system which includes four Minuette L-MPS (Multi-Purpose Satellite) speakers and one Minuette Center-Channel speaker. The Minuette L-MPS speakers reproduce sound for the front and rear channels, while the Minuette Center-Channel speaker enhances dialogue from the center channel. To help plan your system, study the drawing (shown in Figure 1) to determine a placement that best suits your needs. TELEVISION MINUETTE L-MPS SPEAKER For Left ChannelMINUETTE L-MPS SPEAKER For Right Channel COUCH MINUETTE CENTER CHANNEL SPEAKER On Top Of Television For Center Channel INFINITY POWERED SUBWOOFER (optional) MINUETTE L-MPS SPEAKER Left Rear SurroundMINUETTE L-MPS SPEAKER Right Rear Surround FIGURE 1.In this overhead view of a typical 6-piece home enter- tainment system, Minuette L- MPS speakers are used to reproduce sound for the front and rear (surround) channels. The Minuette Center-Channel speaker is used to enhance center-channel dialogue. An optional Infinity Powered Subwoofer is shown providing extra bass for effects and music. PLACEMENT FRONT PLACEMENT Using speaker stands or bookshelves, place a pair of L-MPS speakers on their bases (included) and place on either side of the television. They can be aimed at the viewing audience, if desired (see Figure 1). Experiment with different placement to find the most pleasing effect for your system. NOTE: Minuette L-MPS speakers may be placed vertically on their bases or horizontally (see Figures 2 and 3 on the next page). For wall and ceiling mounting, L-MPS speakers can be installed in a variety of ways, as shown in Figures 5 through 8 (on the next two pages). You can mount the speakers directly with screws (not included), or use the enclosed mounting brackets. Locate a stud for secure mounting. Use heavy-duty screws with long threads so there is an adequate number of threads holding the speaker (or speaker/bracket) to the wall. Test the mounting thoroughly before final installation. REAR PLACEMENT For rear channel placement, follow the same procedure for front placement, except place a pair of L-MPS speakers slightly behind or ahead and above either side of the viewing audience (see Figure 1). CENTER PLACEMENT Place your Minuette Center-Channel speaker on top of the television (see Figure 4 on the next page). Aim it directly at the viewing audience (see Figure 1), so that center channel dialogue is heard correctly. L-MPS Theater Pac Manual 9/11/98 2:49 PM Page 2
Page 2
3 L-MPS HORIZONTAL PLACEMENT rotate logo FIGURE 3.Free-standing horizontal placement of L-MPS speaker. L-MPS VERTICAL PLACEMENT rotate logo base FIGURE 2.Free-standing vertical placement of L-MPS speaker. NOTE: Use the enclosed base for added stability. L-MPS VERTICAL MOUNTING DIRECTLY ON WALL (Rear View) Wood Screws (fasten to wall stud) Slide Speaker Down Onto Wood Screws FIGURE 5.For vertical mounting of the L-MPS speaker directly on a wall, fasten the wood screws (not included) to a desired wall stud, leaving a 1Ú8" clearance between the screw head and the wall. Rotate the L-MPS speaker vertically, align the keyholes on the rear of the speaker with the wood screws, and slide speaker down. MINUETTE CENTER-CHANNEL PLACEMENT rotate logo FIGURE 4.Free-standing horizontal placement of the Minuette Center-Channel speaker. Note logo orientation. L-MPS Theater Pac Manual 9/11/98 2:49 PM Page 3
