Page 2

MODEL KH-lOOéI. SERVICE MANUAL

NAME OF THE PARTS

TELESCOPIC
ANTENNA

I
. ' TUNING
~/ CONTROL

:/0N-0FF SWITCH
; &
I VOLUME CONTROL

EARPHONE

JACK \

=V4-AUTO ANTENNA
JACK

TONE SWITCH

V DISASSEMBLY

HOW TO REMOVE THE PRINTED CIRCUIT BOARD
After taking out the battery case, pull out the two knobs
(TUNING CONTROL, ON >OFF SWITCH & VOLUME
CONTROL).

Remove two studs and ﬁve screws shown in Fig. 1.

Fig. 1
SCREWS HOLDING
CIRCUIT BOARD
HOW TO LOOP THE DIAL CORD , the knotched section of dial pulley shown in Fig. 2.
After taking out the chassis, move the dial pointer to the 3) Loop the dial cord according to each arrow's direction
low frequency by tuning knob. Refer to Fig. 2. as shown in Fig. 2.
1) Cut the dial cord to 25%'. 4) After the dial pointer to punched position on the rail
2) Turn the tuning shaft fully counterclockwise and set and fix it to the dial cord.
IAL POINTER
[o-' ° [-0
O 2
__l .
, G E!
PULLEY 3 TURNS PULLEY
w
(TUNING CONTROL
SHAFT '
DIAL PULLEY

Dial cord and dial pointer mechanism

VARIABLE CAPACITO

Fig. 2
