Page 2
MODEL KCT-IQIOH SERVICE MANUAL
CONTROLS
EJECT BUTTON
RECORDNG BAND SELECTOR
LEVEL METER I
BUTTON --,
REWIND BUTTON-VT. v TELESCOPIC N
PLAI BUTTON I / ANTENNA { , ,.
STOP BUTTON-U; fl '7 (l 3'" fiiighTAPE
MW, TUNING MICROPHONE
L CONTROL '; / {/JAC K
«ON/OFF SWITCH & wmf _ REMOTE CONTROL
.- VOLUME CONTROL I - /JACK
, \TONE CONTROL 7 ;/O. UTPUT JACK
ACCESSORMWNAUX. IN JACK
COM PARTMENT / \MONITOR
I: BATTERY LID AC POWER SOCKET SWITCH
Fig l 1-" . 2
DISASSEMBLY 3
l. licmoval of back cover 2. Removal of chassis
Remove {our screws holding rear case as shown in Fig. 3. Remove knobs. Remove eight screws holding chassis as
Be careful not to cut telescopic antenna wire accidentally. shown in Figs 4 and 5.
CHASSIS HOLDING SCREWS
BACK COVER HOLDING SCREWS
Fig. 3
3. Removal of circuit board
Remove seven screws holding circuit board and two screws
holding jack board as shown in Fig. 6. Be careful not to cut
vnres accidentally. _ CHASSIS HOLDING SCREWS
CIRCUIT BOARD HOLDING SCREWS
JACK BOARD ,
HOLDING SCREWS
Qxa/
