Hitachi DVDS 163 Service Manual

This is the 72 pages manual for Hitachi DVDS 163 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 72

Extracted text from Hitachi DVDS 163 Service Manual (Ocr-read)

Page 1

Contents - 1 Table of Contents 1 Safety Precaution for Repair............ 1-1 1-1 Cautions .................................................. 1-1 1-2 Electrostatic Protection Measures ........... 1-2 1-3 Cautions When Handling DVD Drive ....... 1-2 1-4 Cautions When Handling HDD ................ 1-3 1-5 Lead-Free Solder ..................................... 1-4 1-6 Notes When Using Service Manual ......... 1-5 2 General Description .......................... 2-1 2-1 Overview ................................................. 2-1 2-1-1 Service method .................................... 2-1 2-1-2 Disc information .................................... 2-2 2-2 Speciﬁ cations .......................................... 2-4 2-3 Major Differences from Previous Model .. 2-5 2-4 Function Differences from Previous Model ....................................... 2-6 2-5 Names of Parts ........................................ 2-7 2-6 HDMI Connection .................................... 2-10 2-7 List of Abbreviations and Terms for DVD Recorder .................................................. 2-11 3 Details of Servicing and Troubleshooting ................................ 3-1 3-1 How to Remove Disc from Faulty Recorder .................................................. 3-1 3-2 Initialization .............................................. 3-2 3-2-1 Factory Set .......................................... 3-2 3-2-2 HDD Format ........................................ 3-2 3-3 Troubleshooting HDD .............................. 3-3 3-4 Checking Versions of Firmware and Updating ................................................. 3-4 3-4-1 Version check procedure ...................... 3-4 3-4-2 Method of starting up ﬁ rmware update program ................................................ 3-4 3-4-3 Main ﬁ rmware updating procedure ...... 3-5 3-4-4 Loader ﬁ rmware updating procedure .. 3-6 3-4-5 Main/Loader ﬁ rmware simultaneous updating procedure .............................. 3-6 3-5 Troubleshooting ....................................... 3-7 3-5-1 Troubleshooting electronic system ....... 3-7 4 Disassembly and Reassembly......... 4-1 4-1 Order of Disassembly .............................. 4-1 4-2 Disassembly ............................................ 4-2 (1) Top Cover, Fan .......................................... 4-2 (2) Front Block ................................................ 4-3 (3) TIMER-1 P.C.B, TIMER-2 P.C.B, Front Panel ................................................ 4-3 (4) MAIN P.C.B ............................................... 4-4 (5) Power Cable, SMPS P.C.B ........................ 4-5 (6) HDMI Block, HDMI P.C.B .......................... 4-6 (7) Front Frame, DVD Block, DVD Drive Unit, LOADER P.C.B .......................................... 4-7 (8) HDD Block, HDD P.C.B, HDD ................... 4-8 (9) CARD P.C.B .............................................. 4-9 (10) I/O P.C.B .................................................. 4-10 (11) Rear Panel .............................................. 4-10 5 Exploded View and Parts List .......... 5-1 5-1 Exploded View ......................................... 5-1 5-2 Parts List ................................................. 5-2 S Schematic, Wiring Diagrams ............ S-1 S-1 Wiring Diagram ........................................ S-1 S-2 SMPS Schematic Diagram ...................... S-2 S-3 POWER Schematic Diagram (I/O P.C.B) .... S-3 S-4 TUNER/SYSTEM Schematic Diagram (I/O P.C.B) ................................................ S-4 S-5 JACK Schematic Diagram (I/O P.C.B) ...... S-5 S-6 DECODER Schematic Diagrams (I/O P.C.B) ................................................ S-6 S-7 TIMER-1,TIMER-2 Schematic Diagram (TIMER-1,TIMER-2 P.C.B) ....................... S-7 S-8 HDMI Schematic Diagram (HDMI P.C.B) ..S-8 - TO BE ADDED - S-9 Circuit Waveforms .................................... S-9 S-10 Circuit Voltage Chart .............................. S-10 C Circuit Board Diagrams .................... C-1 C-1 I/O Circuit Board Diagram ....................... C-1 C-2 SMPS Circuit Board Diagram .................. C -3 C-3 TIMER-1 Circuit Board Diagram .............. C- 3 C-4 TIMER-2 Circuit Board Diagram .............. C- 3 C-5 HDMI Circuit Board Diagram ................... C- 4 C-6 HDD Circuit Board Diagram .................... C- 4
