Hitachi D 75 S Service Manual

Page 1

D-755
(u, c, w, rs, as, AU)

@HITACHI

SERVICE MANUAL sunfish No.1192

@®®.® ® ® 03

KEY TO ILLUSTRATIONS

1. Play Indicator 10. Input Selector 17. Pause Button

2. Recording Indicator 11. Recording Level Control 18. Record Button

3. Pause Indicator (Left/Right) 19. Stop Button

4. Auto Rewind Switch 12. Output level Control 20. Fast Fomard Button
5. Tape Counter 13. Dolby NR/MPX Filter Switch 21. Playback Button

6. Tape Position Indicator 14. Tape Selector Switch 22 Rewind Button

7. Dolby Indicator 15. Eject button 23. Headphone Socket
8. Digital Peak Meter 16. Rec. Mute Button 24. Power (Mains) Switch
9. Microphone Sockets

(left/mono and Right)
SAFETY PRECAUTION

The following precautions should be observed when servicing.

1. Since many parts in the unit have special safety related characteristics, always use genuine Hitachis replacement
parts. Especially critical parts in the power circuit block should not be replaced with those of other manufactures.
Critical parts are marked with A in the schematic diagram, and circuit board diagram.

2. Before returning a repaired unit to the customer, the service technician must thoroughly test the unit to ascertain
that it is completely safe to operate without danger of electrical shock.

Nol- :
U ....... USA F5 ...... Switzerland and Scandinavia C ....... Canada
w ...... General Area as ...... Great Britain AU ..... Australia

STEREO CASSETTE TAPE DECK

June1979
