Page 2

INTRODUCTION

Congratulations. You have just purchased one of the finest stereophonic
music centers available. Your receiver represents the successful culmination of
many years of intensive research in solid-state technology-a product literally

born of space-age development. Before you lies the magnificent sound of
recorded music as you have never heard it before.

We know how anxious you are to install and listen to your new receiver.
However, a few moments spent in reading this instruction booklet will pay
vast dividends in the ultimate enioyment of y0ur music system.

Please retain this booklet for it contains valuable information.

lItlulllllalllllllllllllllllltflllIlmmmmmmflmmnlmmmmlmmIlllllllllfllllllllfllllllllfllfllllflllfllllllilllllllllllllfllllflllIIlllllllllllllllIIllllIIlllllllllllllllIlfllllllllllmlllmlllllllllllllllllfllflllllWillllllllllllllllllllllllllllllllllllIllllllillllllllllllllllllllIllllllllllllllllllllllllllllllli

WARRANTY POLICY

Please fill in your warranty card and mail it to the factory without delay
to protect your rights under warranty. The Harman-Kardon warranty is not valid
unless we have your card on file.

WARRANTY

We warrant each unit to be free from defects in material and workmanship
under normal use and service, and in accordance with the conditions herein

below set forth, for a period of two (2) years from date of delivery to the

Original purchaser.

Should a defect occur within the said two (2) years, and provided that
the unit is returned to us with transportation prepaid and which our examination
shall disclose to our satisfaction to have been thus defective, we will:

1. During the first ninety'l90) days from date of sale at our option, either
replace or repair and install any defective parts, free of charge.

2. After ninety [90) days and for the balance of the two (2) years, 0' 00"
option, either replace or repair all defective parts charging only for labor.

This warranty is not applicable to any instrument which shall have been
repaired or altered in any way so as in our iudgement to affect its stability or
reliability nor which has been subiect to neglect, misuse, abuse, negligence or
accident nor which has had the serial number altered, effaced or removed.

Neither shall this warranty apply to any instrument which has been connected
otherwise than in accordance with instructions furnished by us.

This warranty is expressly in lieu of all other warranties, express or implied,
and of all other abligations or liability on our part, and we neither assume nor

authorize any representative or other person to assume for us any other liability
in connection with the sale of this instrument.

SERVICE POLICY

Harman-Kardon has established a special consumer division to answer all
questions pertinent to the installation and operation of your unit. Please feel
free to write us at any time and we will endeavor to offer prompt and complete
advice.

If your problem cannot be resolved through our combined efforts we may
wish to refer you to one of our authorized warranty stations. The unit must be
shipped via Railway Express, Prepaid to the station designated, accompanied by
a brief note describing the exact nature of the difficulty. Under no circumstances
should the set be shipped directly to the factory without prior authorization!

INSTALLATION PROCEDURE

VENTILATION

Although your new Nocturne Receiver rarely develops high heat, it is still
recommended that you leave the back of the cabinet open. If this is not possible,
provide several large holes or slots as low down and as high up in the cabinet
back as possible. As an alternate, holes may be provided in the sides, bottom
or top of the cabinet. Remember that really effective ventilation requires pro-
vision for cool air to enter at the bottom and hot air to leave at the top. A
minimum clearance of two (2) inches should be allowed on each side and in the

rear, between the chassis and the cabinet, and three (3) inches are required
above it.

lsolate any accessories which might interfere with ventilation. For example,
do not drape plastic or rubber covered interconnecting cable over the equipment.

The rear panel surface of your receiver has been designed as a heat dissi-
pating device for the output transistors. This area will become warm under normal
use and should not be cause for concern.

POWER REQUIREMENTS

Connect the AC line cord into any outlet furnishing l l 7 volts, 50 or 60 cycle
AC current. The voltage may vary between 105 and 125 volts. An auxiliary AC
power outlet is provided on the rear panel of your receiver. Any accessory equip-
ment (tape recorder, phonograph record player, etc.) may be connected to this

receptacle and will be controlled by the ON OFF switch on the front panel of your
receiver.
