Page 1
Technical Specifications 65 Signature 2.0 Signature 2.0 Processor/Tuner Specifications Inputs: Analog Audio: Six Stereo pairs via RCA jacks Digital Audio: Four Coaxial S/P-DIF, Two Optical TosLink External Adapter: Six Direct Analog channels via RCA jacks Composite Video: Six RCA jacks S-Video: Two 4-pin mini DIN IR Sensor Input: 3.5mm mono mini-plug Outputs: Main Audio: Six Analog Outputs via RCA jacks (left, center, right, right surround, left surround, subwoofer) Main Video: One Composite RCA jack output paralleled with one S-Video 4-pin mini DIN Record Audio: Two pair (paralleled) analog via RCA jacks Record Video: One Composite via RCA jack paired with one S-Video via 4-pin mini DIN IR Sensor: Loop-through output via 3.5mm mono mini plug Accessory Trigger: 6 Ð 12 volt DC via 3.5mm mono mini plug, tip positive, 150mA maximum. Surround Modes: Analog: Dolby Pro Logic, Four Movie Modes, Four Music Modes, Stereo, Mono, Mono + Digital: Dolby Digital, Dolby Digital Late Night, Dolby Digital Pro Logic, Dolby DigitalMono, DTS 5.1, DTS 4-Channel, DTS 2-Channel, Stereo, Mono + Preamplifier: Frequency Response: Front Channels (Analog Stereo):20Hz to 50kz, ±0.5dB Center and Surround Channels:20Hz to 30kHz, ±1dB Subwoofer Channel:10Hz to 100Hz, ±1dB THD + N: 0.03%, 20Hz to 20kHz S/N Ratio: >Ð87dBr, 20Hz to 20kHz Crosstalk: <60dB Input Impedance: Audio:>10K½ Video:75½ Output Impedance: Audio:300½ Video:75½ Crossovers: Low Pass:3 Pole (18dB/Octave) @ 100Hz High Pass:3 Pole (18dB/Octave) @ 100Hz ToneControls: Treble Cut:Ð0dB to Ð8dB in 2dB steps @ 10kHz shelving Bass Boost:+0dB to +8dB in 2 steps @ 50Hz Video Standards: NTSC, PAL
Page 2
Technical Specifications 66 Signature 2.0 Signature 2.0 Processor/Tuner Specifications (continued) Tuner Section FM: Frequency Range: 87.5 to 108.0MHz in 200kHz steps Usable Sensitivity: <1.0 µV/11.2dBf Signal-To-Noise: 70dB (Stereo, A-weighted) S/N 50dB Sensitivity: <45dBf THD + N: <0.5% Capture Ratio: <2.5dB AM Suppression: >50dB Image Rejection: >70dB (@ 106MHz) IF Rejection: >85dB Effective Selectivity: >50dB (±400kHz) Stereo Separation: >40dB (1kHz) RDS Modes: Station ID, Program Type, Radio Text Data, Program Type Search Tuner Section AM: Frequency Range: 520 Ð 1710 kHz in 10kHz steps Signal-To-Noise Ratio: >40dB Usable Sensitivity: ²500µV/M Selectivity: ³30dB (±10kHz) General: Power Requirement: AC 115V/60Hz Power Consumption: 5.5W Idle, 75W Maximum Dimensions: (Max, including knobs, jacks, buttons) Width:17 3Ú8inches (441mm) Height:4 1Ú8inches (105mm) Depth:15 3Ú8inches (395mm) Weight: 22 lbs. (10.5 kg) All features and specifications are subject to change without notice. *Trademarks of Dolby Laboratories. DTS and DTS Surround are trademarks of Digital Theater Systems.
