SPECIFICATIONS

Nominal Limit
HMS Output Power
89,1kHz, THD 0.1%
49,1kHz, THD 0.1%
High Instantaneous Current
Capability (HCC) 18A
Half Power Bandwith * 10H: ~ 90kHz
Frequency Response at ~3dB 4H2 ~ 110kHz
Usable Sensitivity

24w 2 20w
38W 2 saw

Video/CD, Tuner 135mVi 25mV
Phono 2.2mV i 0.3mV
Signal to Noise Ratio
Video/CD, Tuner 86dB 278dB
Phono sous 272m;
Channel Separation at 10 kHz
Video/CD,Tuner 57dB Z45dB
Phono 56dB ZSOdB
IM Distortion Ratio 0.03%SO.1%
Damping Factor at lkHz 85 260
Tone Control Characteristics
Bass at 50 Hz
Boost 10d B i 2d B
Cut -10d B i 2d B
Treble at 10kHz
Boost 10d B 1 2d B
. _ _ Cut -10dBtZdB

Nominal Limit

Loudness Control (with Volume
control at -40dB)

at IOkHz 3dBt 1.5dB

at 50HZ IOdBi 2dB
DC Output Voltage

L channel 0mV i 60mV

R channel DmV i GOmV

RIAA Equalization 0.6dB S1.5dB/0.2dB S 1.5dB
at Tape Out (20Hz/20kHz)
(No load)

Phono Overload (No load)

Dimensions (W x H x D)

140mv 2100mv

17-1/2" x 4-1/16" x 13-7/8"
(443 x 103 x 353 mm)
Weight 12 lbs. 13 oz. (5.8 kg)
Power Supply

U.S.A. and Canada models AC120V, 13on

General and German models A0220/240V, 50/60Hz
Power Consumption

U.S.A. and Canada models

General and German models

165W
120W

This specification is the target of servicing. But, there is a case
that the specification is not applicable to the measurement
condition and instrument.

Specifications and components subject to change without notice.
Overall performance will be maintained or improved.

LEAKAGE TEST (FOR SERVICE ENGINEERS IN THE U.S.A.)

Before returning the unit to the user, perform the following safety checks:

1. Inspect all lead dress to make cer-
tain that leads are not pinched or
that hardware is not lodged be-
tween the chassis and other metal
parts in the unit.

2. Be sure that any protective devices
such as nonmetallic control knobs,
insulating fishpapers, cabinet backs,
adjustment and compartment cov-
ers or shields, isolation resistor-
capacity networks, mechanical in-
sulators, etc. which were removed
for servicing are properly reinstalled.

3. Be sure that no shock hazard exists; check for leakage

current using Simpson Model 229 Leakage Tester,
standard equipment item No. 21641, RCA Model
WT540A or use alternate method as follows:
Plug the power cord directly into a 120-volt AC
receptacle (do not use an Isolation Transformer for
this test). Using two clip leads, connect a 1500
Ohm, 10-watt resistor paralleled by a 0.15uF capac-
itor, in series with all exposed metal cabinet parts
and a known earth ground, such as a water pipe or
conduit. Use a VTVM or VOM with 1000 Ohms per
volt, or higher, sensitivity to measure the AC voltage
drop across the resistor. (See Diagram.) Move the
resistor connection to each exposed metal part having
a return path to the chassis (antenna, metal, cabinet,
screw heads, knobs and control shafts, escutcheon,
etc.) and measure the AC voltage drop across the
resistor. (This test should be performed with the
power switch in both the On and Off positions.)

in
N
to
E
0.

TO EACH EXPOSED
METAL SURFACE OF
UNITUNDER TEST

SlMPSON MODEL 229 ETC. FOR
LEAKAGE TEST

TO AC GROUND SUCH

HIGH
VOLTAGE
OR +LEAD

GROUND
LEAD

CON DU IT, ETC.

VTVM
-0 Ac SCALEo.

1.5kn
10W

W

0.15/JF

TEST PROBE

TO EXPOS ED
M ETAL PARTS

CONNECT T0 KNOWN
EARTH GROUND

A reading of 0.35 volt RMS or more is excessive and indicates a potential shock hazard which must be corrected before

returning the unit to the owner.

AS WATER 0R BX CABLE,
