Page 2

SPECIFIC TION

Congratulations on your purchase of the Harman
Kardon hk590i Digital Synthesized Quartz-locked
Stereo Receiver.

in order to appreciate the full performance of
this sophisticated unit, please be sure to read this
owners manual and use your receiver only in
accordance with its instructions. Keep it in safe
place for future reference.

it CAUTION i'i
msx or ELECTHIC suocx
no not OPEN .

CAUTION; TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USERSERVICEABLE PARTS INSIDE REFER SERVIC»
ING TOQUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol] within an
equilateral triangle, is intended to alert the user of the
presence of uninsulated "dangerous voltage" within the
products enclosure, that may be of sufficient magni-
tude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is
intended to alert the user of the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

9%

WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS UNIT TO RAIN OP. MOISTURE.

Audio Section

Power Output, RMS
(both channel driven into
8 Ohms, 2OHZ - 20kHZ)

HCC (high instantaneous
current capability)

Power Bandwidth (at half
rated output into 8 Ohms)

Frequency Response

(+0, -3dBI
Signal to Noise Ratio,
A" WTD
Phono
Aux/DAD
Input Sensitivity/l mpedance
Phono
Aux/DAD

Tone Control Characteristics
Bass Turnover Frequency
Treble Turnover Frequency

Loudness Control
(-40dB Position)
at BOHZ/at 10kHZ

Filter
Subsonic

Tuner Section
Usable FM Sensitivity (Mono)

50dB Ouieting Sensitivity
Mono
Stereo

Alternate Channel Selectivity
Stereo Separation IlkHz)

FM THD
(iKHz, 100% modulation)
Mono/Stereo

AM Sensitivity
(external antenna)
General

Dimensrons (W x H x D)
(with legs, knobs, antenna)

Weight
Power Supply
Power Consumption

: 45 watts per channel

@ less than 0.08% THD

. 35A

', IOHZ »- TOODOOHZ

. le - 120,000Hz

:80dB
:82dB

: 2.2mV/47k Ohms
: lSOmV/25k Ohms

Z 2OOHZ/4OOHZ
: 2kHZ/6kHz

: IOdB/SdB

: 15H2, 6dB/Octave

: 10.8dBf ll.9uVI

: 15.ldBf (3.1uV)
: 36.6dBf [37pVI

: 6808
: 48dB

: C.08%/0.1°/a
: l7uV

: 17-7/15 X 571/4" X 1473/8"

(443 x 134 x 365mm)

. 17|bs,10oz, (8kg)
: AC 120V, 60Hz
: 310W
