Harman kardon hk 3470 owners manual
This is the 20 pages manual for harman kardon hk 3470 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from harman kardon hk 3470 owners manual (Ocr-read)
Page 1
2TABLE OF CONTENTS 3Introduction 3Safety Information 4Unpacking 5Front Panel Controls 7Front Panel Information Display 8Rear Panel Connections 10Remote Control Functions 12Installation and Connections 14Operation 14Basic Operation 14Source Selection 14Tuner Operation 15Tape Recording 16Remote Control Operation 17Programming the Remote 19Memory Backup 19Processor Reset 19Troubleshooting Guide 20Technical Specifications HK 3470Stereo Receiver Typographical Conventions In order to help you use this manual with the remote control, front panel controls and rear panel connections, certain conventions have been used. EXAMPLE– (bold type) indicates a specific remote control or front panel button, or rear panel connection jack EXAMPLE– (OCR type) indicates a message that is visible on the front panel information display EXAMPLE– (outlined type) indicates a lit indicator in the front panel information display 1– (number in a square) indicates a specific front panel control å– (letter in a circle) indicates a button or indicator on the remote ¡– (number in a circle) indicates a rear panel connection A– (letter in a square) indicates an indicator in the front panel display
Page 2
3INTRODUCTION Introduction Congratulations!With the purchase of the Harman Kardon HK 3470 you are about to begin many years of listening enjoyment. The HK 3470 has been custom-designed to provide all the excitement and power of rock, jazz and popular music, and every nuance of classical selections. While sophisticated systems are hard at work within the HK 3470 to make all of this happen, hookup and operation are simple. Color-keyed connections and a comprehensive remote con- trol make the HK 3470 easy to use. To obtain maximum enjoyment from your new receiver, we urge you to take a few minutes to read through this manual. This will ensure that connections to speakers, source playback units and other external devices are made properly. In addition, a few minutes spent learning the functions of the various controls will enable you to take advantage of all the power the HK 3470 is able to deliver. If you have any questions about this product, its installation or operation, please contact your dealer, your best local source of information. Description and Features Harman Kardons HK 3470 is the worlds first stereo receiver to offer VMAx ®. VMAx is a pro- prietary signal-processing technique that cre- ates an open, spacious sound field when only two loudspeakers are available. VMAx circuitry is able to decode the ambience of a concert hall or theater from a stereo recording. The HK 3470 is a full-featured stereo receiver, with five inputs and an FM Stereo/FM/AM tuner with capabilities that provide for the utmost flexibility. A high-quality phono input is avail- able so that you may continue to enjoy your existing record collection as well as the latest CD recordings. The HK 3470s powerful amplifier uses traditional Harman Kardon High-Current Design philosophies to meet the wide dynamic range of any program selection. Harman Kardon invented the high-fidelity receiver more than forty-seven years ago. With state-of-the-art features and time-honored cir- cuit designs, the HK 3470 is one of the finest receivers ever offered by Harman Kardon.Harman Kardon-Designed High- Current, Ultrawide-Bandwidth Amplifier VMAx Processing Mode – Exclusive to Harman Kardon Receivers Phono Input Section Speaker 1/Speaker 2 Outputs for High- Quality Sound in Two Locations Pre-Out/Main-In Jacks for Use With External Amplifiers, Equalizers or Speaker Processors Programmable Learning Remote Control Subwoofer Outputs Important Safety Information Verify Line Voltage Before Use Your HK 3470 has been designed for use with 120-volt AC current. Connection to a line volt- age other than that for which it is intended can create a safety and fire hazard, and may dam- age the unit. If you have any questions about the voltage requirements for your specific model, or about the line voltage in your area, contact your sell- ing dealer before plugging the unit into a wall outlet. Do Not Use Extension Cords To avoid safety hazards, use only the power cord attached to your unit. We do not recom- mend that extension cords be used with this product. As with all electrical devices, do not run power cords under rugs or carpets or place heavy objects on them. Damaged power cords should be replaced immediately with cords meeting factory specifications. Handle the AC Power Cord Gently When disconnecting the power cord from an AC outlet, always pull the plug – never pull the cord. If you do not intend to use the unit for any considerable length of time, disconnect the plug from the AC outlet. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: To prevent electric shock, do not use this (polarized) plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
