Harman kardon ep 730 owners manual
This is the 5 pages manual for harman kardon ep 730 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from harman kardon ep 730 owners manual (Ocr-read)
Page 2
Construction 1. 3.5mm Stereo input plug 2. Shirt clip 3. Bass Boost / Volume control 4. Earphone Dimensional Layout Technical SpecificationManufacturer: Harman Consumer Group, Inc. Model: EP 730 Available in: Black or White Input Requirement: Main connection – 3.5mm mini stereo jack Max Power Input: 45 mW (HF mode)/16 mW (B mode) Dimensions: Wire length – 150cm Compatibility: All audio output devices with a 3.5mm or stereo phono audio jack Sensitivity (@ 1kHz): 95dB SPL (max VC) for a 0.1V RMS input in HF position 105dB SPL (fixed) for a 0.1V RMS input in B position Impedance: 48 Ohms (HF mode); 16 ohms (B) Noise Isolation: 35 dB (three-flange ear tip deeply seated) 40 dB (foam ear tip deeply seated) Frequency Response: 20 Hz ~ 15 kHz Weight: 20.0 Grams (1.5m cable included) HF – High Fidelity Most accurate response + VC B- Bass Boost Bass and loudness boost- No VC VC-Volume Control Bass Boost/Volume Control
