Harman Consumer Group 250 Crossways Park Dr. Woodbury, New York 11797 Email Techsupport@harman.com Web www.harmanservice.com DPR 1005 / 2005 Block Diagram A: Voltage Doubler and inrush B: Over Voltage protect C: Over Current protect D: Over Current / Voltage protect E: Multi Voltage SMPS F: Mosfet Bridge Figure 1 Page 2
