Harman kardon dc 520 owners manual
This is the 12 pages manual for harman kardon dc 520 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from harman kardon dc 520 owners manual (Ocr-read)
Page 1
Eject Input Balance Headphones on Mode Cont PlayOff B C Dolby NRInput Level Reset Sync Rev PRIMARY Transport Auto Tape Selector Dual Auto ReverseREC/PLAY Reset Copy Record High Speed Copy Rec Mute Harman Kardon DC520 Dual Cassette Deck Owners Manual DC520 Ð 8¥16¥96 ver (D) Ð (Front Cover) -DC520 (d).qx 11/6/96 12:02 Page 2
Page 2
Owners Manual DC520 Dual Cassette Deck Table of Contents Introduction and Safety Information . . . . . . . . . . . . . . . . . . . . 1–2 Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Front Panel Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–8 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 ©1996 Harman Kardon, Incorporated 80 Crossways Park West Woodbury, NY 11797 DC520 Ð 8¥14¥96 ver (B) Inside Front Cover CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU'AU FOND. The lightning flash with arrowhead symbol, within an equalateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to consittute a risk of electric shock to persons.The exclamation point within an equalateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. CAUTION RISK OF ELECTRICAL SHOCK DO NOT OPEN CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE THE GROUNDING PLUG ON THE POWER CORD, OR USE ANY PLUG OR EXTENSION CORD THAT DOES NOT HAVE A GROUNDING PLUG PROVIDED. MAKE CERTAIN THAT THE AC OUTLET IS PROPERLY GROUNDED. DO NOT USE AN ADAPTER PLUG WITH THIS PRODUCT. -DC520 (d).qx 11/6/96 12:02 Page 3
