Harman kardon avr 65 owners manual
This is the 52 pages manual for harman kardon avr 65 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from harman kardon avr 65 owners manual (Ocr-read)
Page 1
Safety Information Important Safety Information Verify Line Voltage Before Use YourAVR65hasbeendesignedforuse with120-voltACcurrent.Connectiontoa linevoltageotherthanthatforwhichit isintendedcancreateasafetyandfire hazardandmaydamagetheunit. If you have any questions about the volt- age requirements for your specific model, or about the line voltage in your area, contact your selling dealer before plug- ging the unit into a wall outlet. Do Not Use Extension Cords To avoid safety hazards, use only the power cord attached to your unit. We do not recommend that extension cords be used with this product. As with all electri- cal devices, do not run power cords under rugs or carpets or place heavy objects on them. Damaged power cords should be replaced immediately with cords meeting factory specifications. Handle the AC Power Cord Gently When disconnecting the power cord from an AC outlet, always pull the plug, never pull the cord. If you do not intend to use the unit for any considerable length of time, disconnect the plug from the AC outlet. Do Not Open The Cabinet There are no user-serviceable compo- nents inside this product. Opening the cabinet may present a shock hazard, and any modification to the product will void your guarantee. If water or any metal object such as a paper clip, wire or a staple accidentally falls inside the unit, disconnect it from the AC power source immediately, and consult an authorized service station. CATV or Antenna Grounding If an outside antenna or cable system is connected to this product, be certain that it is grounded so as to provide some pro- tection against voltage surges and static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding of the mast and sup- porting structure, grounding of the lead- in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes and requirements of the grounding electrode. NOTE TO CATV SYSTEM INSTALLER: Thisreminderisprovidedtocallthe CATV(CableTV)systeminstallersatten- tiontoarticle820-40oftheNECthat providesguidelinesforpropergrounding and,inparticular,specifiesthatthecable groundshallbeconnectedtotheground- ingsystemofthebuilding,asclosetothe pointofcableentryaspossible. Installation Location nTo assure proper operation, and to avoid the potential for safety hazards, place the unit on a firm and level sur- face. When placing the unit on a shelf, be certain that the shelf and any mounting hardware can support the weight of the product. nMake certain that proper space is pro- vided both above and below the unit for ventilation. If this product will be installed in a cabinet or other enclosed area, make certain that there is suffi- cient air movement within the cabinet. Under some circumstances a fan may be required. nDo not place the unit directly on a carpeted surface. nAvoid installation in extremely hot or cold locations, or an area that is exposed to direct sunlight or heating equipment. nAvoid moist or humid locations. nDo not obstruct the ventilation slots on the top of the unit, or place objects directly over them. 2 AVR65 120 volt Rev (C) 10/6/98 CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU'AU FOND. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN
Page 2
Safety Information Cleaning When the unit gets dirty, wipe it with a clean, soft, dry cloth. If necessary, wipe it with a soft cloth dampened with mild soapy water, then a fresh cloth with clean water. Wipe dry immediately with a dry cloth. NEVER use benzene, aerosol cleaners, thinner, alcohol or any other volatile cleaning agent. Do not use abrasive cleaners, as they may damage the finish of metal parts. Avoid spraying insecticide near the unit. Moving the Unit Before moving the unit, be certain to dis- connect any interconnection cords with other components, and make certain that you disconnect the unit from the AC outlet. Important Information For the User NOTE:This equipment has been tested and found to comply with the limits for a Class-B digital device, pursuant to Part 15 of the FCC Rules. The limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio- frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that harmful interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television recep- tion, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the inter- ference by one or more of the following measures: nReorient or relocate the receiving antenna. nIncrease the separation between the equipment and receiver. nConnect the equipment into an outlet on a circuit different from that to which the receiver is connected. nConsult the dealer or an experienced radio/TV technician for help. ThisdevicecomplieswithPart15ofthe FCCRules.Operationissubjecttothe followingtwoconditions:(1)thisdevice maynotcauseharmfulinterference,and (2)thisdevicemustacceptinterference received,includinginterferencethatmay causeundesiredoperation. NOTE:Changes or modifications may cause this unit to fail to comply with Part 15 of the FCC Rules and may void the users authority to operate the equipment. Unpacking The carton and shipping materials used to protect your new receiver during ship- ment were specially designed to cushion it from shock and vibration. We suggest that you save the carton and packing materials for use in shipping if you move, or should the unit ever need repair. To minimize the size of the carton in storage, you may wish to flatten it. This is done by carefully slitting the tape seams on the bottom and collapsing the carton down to a more two-dimensional appearance. Other cardboard inserts may be stored in the same manner. Packing materials that cannot be collapsed should be saved along with the carton in a plastic bag. If you do not wish to save the packaging materials, please note that the carton and other sections of the shipping protec- tion are recyclable. Please respect the environment and discard those materials at a local recycling center. Typographic Conventions In order to help you use this manual with the remote control, front panel controls and rear panel connections, certain conventions have been used. EXAMPLE – (bold type) indicates a specific remote control or front panel button, or rear panel connection jack EXAMPLE – (OCR type) indicates a message that is visible on the front panel information display EXAMPLE – (bold type) indicates a lit indicator in the front panel information display 1 – (number in a square) indicates a specific front panel control a – (number in an oval) indicates a button or indicator on the remote Á – (number in a circle) indicates a rear panel connection A – (letter in a square) indicates an indicator in the front panel display 3 AVR65 120 volt Rev (C) 10/6/98
